Basic NEC with Broadcast Applications

Basic NEC with Broadcast Applications

by J.L. Smith
Released October 2020
Publisher(s): Routledge
ISBN: 9781136031212

Read it now on the O’Reilly learning platform with a 10-day free trial.

O’Reilly members get unlimited access to books, live events, courses curated by job role, and more from O’Reilly and nearly 200 top publishers.

Start your free trial

Book description

Basic NEC with Broadcast Applications addresses computer modeling of MF directional broadcast antennas and illustrates the assets and liabilities of the Numerical Electromagnetic Code (NEC). The book's "how to" approach reveals the fundamentals of NEC operation, teaches broadcast applications and shows the reader how to use NEC-2 to: model non-radiating networks, verify calculations, detune unused towers, design top-loaded and skirted antennas, minimize coding by moving and duplicating structures, and much more! Complete with downloadable resources, the book is an invaluable toolkit with software necessary for the design and analysis of broadcast antenna arrays.
