Book description
The MEMS (Micro Electro-Mechanical Systems) market returned to growth in 2010. The total MEMS market is worth about $6.5 billion, up more than 11 percent from last year and nearly as high as its historic peak in 2007. MEMS devices are used across sectors as diverse as automotive, aerospace, medical, industrial process control, instrumentation and telecommunications – forming the nerve center of products including airbag crash sensors, pressure sensors, biosensors and ink jet printer heads. Part of the MEMS cluster within the Micro & Nano Technologies Series, this book covers the fabrication techniques and applications of thick film piezoelectric micro electromechanical systems (MEMS). It includes examples of applications where the piezoelectric thick films have been used, illustrating how the fabrication process relates to the properties and performance of the resulting device. Other topics include: top-down and bottom-up fabrication of thick film MEMS, integration of thick films with other materials, effect of microstructure on properties, device performance, etc.
- Provides detailed guidance on the fabrication techniques and applications of thick film MEMS, for engineers and R&D groups
- Written by a single author, this book provides a clear, coherently written guide to this important emerging technology
- Covers materials, fabrication and applications in one book
Table of contents
- Cover image
- Table of Contents
- Front Matter
- Copyright
- Preface
- Acknowledgments
- Introduction
- Chapter 1. Integration and devices
- 1.1. Introduction
- 1.2. Structure of Film Devices
- 1.3. Obstacles to Integration
- 1.4. Overcoming Challenges
- 1.5. Overview of Functional Devices
- Chapter 2. Routes to thick films
- 2.1. Introduction
- 2.2. Routes to Achieve Non-thick–Thick Films
- 2.3. Thick-film Powder-based Routes
- 2.4. Modified Powder Routes
- 2.5. Powder Manufacturing Routes
- 2.6. Milling
- Chapter 3. Thick-film deposition techniques
- 3.1. Introduction
- 3.2. Creating Stable Inks
- 3.3. Components of Inks
- 3.4. Directed Coating Techniques
- 3.5. Spreading Coating Techniques
- 3.6. Immersion Coating Techniques
- 3.7. Post-production Poling
- 3.8. Help! It has All Gone Wrong
- Chapter 4. Microstructure–property relationships
- 4.1. Introduction
- 4.2. Material Properties
- 4.3. Why are Film Properties not the Same as Bulk Properties?
- 4.4. Microstructural Variations
- 4.5. Functional Properties
- 4.6. Mechanical Properties
- 4.7. Cracking
- 4.8. Interrelationship Between Property–Microstructure Relationships
- Chapter 5. Patterning
- 5.1. Introduction
- 5.2. Subtractive Patterning
- 5.3. Additive Patterning
- 5.4. Capabilities and Limitations of Patterning
- Chapter 6. Houston, we have a problem
- 6.1. Introduction
- 6.2. Integration
- 6.3. Cracking and Surface Finish
- 6.4. Poor Properties
- 6.5. Patterning
- Chapter 7. Recipes
- 7.1. Powders
- 7.2. Sols
- 7.3. Films and Inks
- 7.4. Processing, Poling, and Useful Stuff!
- Bibliography
- Index
Product information
- Title: Ceramic Thick Films for MEMS and Microdevices
- Author(s):
- Release date: September 2011
- Publisher(s): William Andrew
- ISBN: 9781437778182
