Chapter 5
Transistor Biasing and Stabilisation Circuits
Learning Objectives
To study
- Basic concepts of an Amplifier
- Biasing a Transistor to act as an Amplifier
- Various methods of Biasing BJT, FET and MOSFET devices
- Stability of Amplifier operation
5.1 BASIC CONCEPTS OF AN AMPLIFIER
One of the important applications of BJT/FET is to function as an Amplifier. Each Amplifier stage consists of an active device BJT/FET, ‘R, L, C’ components, signal source and DC voltages. An Amplifier is considered as a four-terminal network (Fig. 5.1) with two ports (input and output ports).
- A signal to be amplified is applied to ‘input port’ of Amplifier and resulting output signal appears at its ‘output port’.
- When output signal is larger than input signal, ...
