IBM Tivoli Storage Resource Manager: A Practical Introduction

Chapter 7. Protecting and maintaining Tivoli Storage Resource Manager 387

7.4 Restore procedures

Figure 7-5 Tivoli Storage Resource Manager restore procedures

We describe now the procedures we have used to recover from:

򐂰 A loss of major Agent files

򐂰 A loss of major Manager files

򐂰 A loss of the Tivoli Storage Resource Manager database

7.4.1 Restore Agent files

In this restore procedure, we have:

򐂰 Stopped the Agent

򐂰 Deleted some files including the Agent executable and configuration file

򐂰 Tried to start the Agent, which failed

򐂰 Restored all of the deleted files

򐂰 Successfully started the Agent

You can see in Example 7-18, all the steps executed to destroy and recover the Agent files.

Example 7-18 Agent restore procedure output

linux:/etc/init.d # ps -ef | grep java

root 4367 4350 0 08:11 pts/0 00:10:04 /opt/tivoli/TSRM/java/bin/exe/java -cp

/opt/tivoli/TSRM/agent/lib/TSRMagt.zip:/opt/tivoli/TSRM/agent/lib/Sprinta2000.jar:/opt/tivo

li/TSRM/agent/lib/ibmjcefw.jar:/opt/tivoli/TSRM/agent/lib/TSRMRequest.jar:/opt/tivoli/TSRM/

agent/lib/ibmpkcs.jar:/opt/tivoli/TSRM/agent/lib/ibmjceprovider.jar:/opt/tivoli/TSRM/agent/

ibm.com/redbooks

Tivoli Storage Resource Manager restore procedures

Tivoli Storage Resource Manager restore procedures

Tivoli Storage Resource Manager Agents

Restore of lost files

Tivoli Storage Resource Manager Server

Restore of lost files

Tivoli Storage Resource Manager database

Database restore command

388 IBM Tivoli Storage Resource Manager: A Practical Introduction

lib/US_export_policy.jar:/opt/tivoli/TSRM/agent/lib/local_policy.jar

com.tivoli.itsrm.agent.svp.Agent

.

.

root 4367 4380 0 08:11 pts/0 00:10:00 /opt/tivoli/TSRM/java/bin/exe/java -cp

/opt/tivoli/TSRM/agent/lib/TSRMagt.zip:/opt/tivoli/TSRM/agent/lib/Sprinta2000.jar:/opt/tivo

li/TSRM/agent/lib/ibmjcefw.jar:/opt/tivoli/TSRM/agent/lib/TSRMRequest.jar:/opt/tivoli/TSRM/

agent/lib/ibmpkcs.jar:/opt/tivoli/TSRM/agent/lib/ibmjceprovider.jar:/opt/tivoli/TSRM/agent/

lib/US_export_policy.jar:/opt/tivoli/TSRM/agent/lib/local_policy.jar

com.tivoli.itsrm.agent.svp.Agent

linux:/etc/init.d # ./tsrmagt1 stop

linux:/etc/init.d #

linux:/etc/init.d # ps -ef | grep TSRMagt1

linux:/etc/init.d #

linux:/etc/init.d # cd /opt/tivoli/TSRM

linux:/opt/tivoli/TSRM #

linux:/opt/tivoli/TSRM # rm config/*

linux:/opt/tivoli/TSRM # rm agent/bin/linux_i386/*

linux:/opt/tivoli/TSRM # cd /etc/init.d

linux:/etc/init.d # ./tsrmagt1 start

linux:/etc/init.d # 06-11 08:49:09 GEN0198I: Agent starting

Exception in thread "main"

linux:/etc/init.d # dsmc restore /opt/tivoli/TSRM/ -subdir=yes -replace=yes

IBM Tivoli Storage Manager

Command Line Backup/Archive Client Interface - Version 5, Release 2, Level 0.0

(c) Copyright by IBM Corporation and other(s) 1990, 2003. All Rights Reserved.

Restore function invoked.

Node Name: SUSE82-1

Session established with server BANDA: AIX-RS/6000

Server Version 5, Release 2, Level 0.0

Server date/time: 06/11/03 16:05:10 Last access: 06/11/03 16:03:04

ANS1247I Waiting for files from the server...

Restoring 176 /opt/tivoli/TSRM/agent [Done]

Restoring 80 /opt/tivoli/TSRM/config [Done]

Restoring 432 /opt/tivoli/TSRM/install [Done]

Restoring 160 /opt/tivoli/TSRM/java [Done]

Restoring 72 /opt/tivoli/TSRM/log [Done]

Restoring 48 /opt/tivoli/TSRM/scripts [Done]

Restoring 80 /opt/tivoli/TSRM/agent/bin [Done]

Restoring 112 /opt/tivoli/TSRM/agent/guid [Done]

Restoring 320 /opt/tivoli/TSRM/agent/lib [Done]

Restoring 168 /opt/tivoli/TSRM/agent/bin/linux_i386 [Done]

...

Restoring 1,025 /opt/tivoli/TSRM/log/suse82-1/Tivoli.Default

Scan.0010_scan.00000413.log [Done]

Restoring 199

/opt/tivoli/TSRM/log/suse82-1/Tivoli.Discovery.0004_discovery.00000371.log [Done]

Restoring 1,930 /opt/tivoli/TSRM/log/suse82-1/agent_000001.log [Done]

Restoring 163 /opt/tivoli/TSRM/log/suse82-1/agent_000002.log [Done]

Restoring 1,069

/opt/tivoli/TSRM/log/suse82-1/db2admin.filling_the_DB_with_scan.0011_scan.00000503.log

[Done]

Restore processing finished.

Chapter 7. Protecting and maintaining Tivoli Storage Resource Manager 389

Total number of objects restored: 281

Total number of objects failed: 0

Total number of bytes transferred: 41.70 MB

Data transfer time: 3.11 sec

Network data transfer rate: 13,716.17 KB/sec

Aggregate data transfer rate: 4,730.41 KB/sec

Elapsed processing time: 00:00:09

linux:/etc/init.d # ./tsrmagt1 start

linux:/etc/init.d # 06-11 09:05:31 GEN0198I: Agent starting

linux:/etc/init.d # ps -ef | grep java

root 4366 1 13 09:10 pts/0 00:00:04 /opt/tivoli/TSRM/java/bin/exe/java -cp

/opt/tivoli/TSRM/agent/lib/TSRMagt.zip:/opt/tivoli/TSRM/agent/lib/Sprinta2000.jar:/opt/tivo

li/TSRM/agent/lib/ibmjcefw.jar:/opt/tivoli/TSRM/agent/lib/TSRMRequest.jar:/opt/tivoli/TSRM/

agent/lib/ibmpkcs.jar:/opt/tivoli/TSRM/agent/lib/ibmjceprovider.jar:/opt/tivoli/TSRM/agent/

lib/US_export_policy.jar:/opt/tivoli/TSRM/agent/lib/local_policy.jar

com.tivoli.itsrm.agent.svp.Agent

.

.

root 4387 4380 0 09:11 pts/0 00:00:00 /opt/tivoli/TSRM/java/bin/exe/java -cp

/opt/tivoli/TSRM/agent/lib/TSRMagt.zip:/opt/tivoli/TSRM/agent/lib/Sprinta2000.jar:/opt/tivo

li/TSRM/agent/lib/ibmjcefw.jar:/opt/tivoli/TSRM/agent/lib/TSRMRequest.jar:/opt/tivoli/TSRM/

agent/lib/ibmpkcs.jar:/opt/tivoli/TSRM/agent/lib/ibmjceprovider.jar:/opt/tivoli/TSRM/agent/

lib/US_export_policy.jar:/opt/tivoli/TSRM/agent/lib/local_policy.jar

com.tivoli.itsrm.agent.svp.Agent

root 4389 4050 0 09:11 pts/0 00:00:00 grep java

From the Tivoli Storage Resource Manager: Administrative GUI we checked to ensure that

the Agent had started successfully (

IBM Tivoli SRM -> Administrative Services -> Agents),

right-click SUSE82-1 and chose Check. Figure 7-5 shows that the Agent on SUSE82-1 did

start.

Figure 7-6 Agent is connected to the server after restore

390 IBM Tivoli Storage Resource Manager: A Practical Introduction

7.4.2 IBM Tivoli Storage Resource Manager Server files

Since our Tivoli Storage Resource Manager Server system also has an Agent running on it,

and the Server and Agent files are stored in the same directory structure, in this restore test

we will be recovering both the Server and Agent.

The restore procedure has the following steps:

1. Stop the Tivoli Storage Resource Manager Server and Agent.

2. Delete Tivoli Storage Resource Manager directories.

3. Try to start the Server - fails.

4. Restore all deleted directories.

5. Successfully start the Tivoli Storage Resource Manager Server and Agent.

Example 7-19 shows the Server and Agent being stopped, the files being deleted, and the

Server and Agent failing to start.

Example 7-19 Stop server and Agent and delete commands

C:\Program Files\Tivoli\TSRM>net stop "IBM Tivoli SRM Server"

The IBM Tivoli SRM Server service is stopping.

The IBM Tivoli SRM Server service was stopped successfully.

C:\Program Files\Tivoli\TSRM>del *.* /s /q >

Deleted file - C:\Program Files\Tivoli\TSRM\autorun.inf

Deleted file - C:\Program Files\Tivoli\TSRM\ibmchanges.txt

Deleted file - C:\Program Files\Tivoli\TSRM\ibmchanges.zip

Deleted file - C:\Program Files\Tivoli\TSRM\INSTANCE1.DAT

Deleted file - C:\Program Files\Tivoli\TSRM\ITSRM_1.2.2.07_windows.zip

Deleted file - C:\Program Files\Tivoli\TSRM\license_key.txt

Deleted file - C:\Program Files\Tivoli\TSRM\license_srm.txt

Deleted file - C:\Program Files\Tivoli\TSRM\SERVER.ID

Deleted file - C:\Program Files\Tivoli\TSRM\setup.exe

Deleted file - C:\Program Files\Tivoli\TSRM\UPTIME.bonnie

Deleted file - C:\Program Files\Tivoli\TSRM\version.txt

Deleted file - C:\Program Files\Tivoli\TSRM\agent\bin\WIN32_I386\TSRMagt.dll

...

C:\Program Files\Tivoli\TSRM>cd ..

C:\Program Files\Tivoli>rmdir tsrm /s

tsrm, Are you sure (Y/N)? y

C:\Program Files\Tivoli>net start "IBM Tivoli SRM Server"

System error 2 has occurred.

The system cannot find the file specified.

C:\Program Files\Tivoli>net start "IBM Tivoli SRM Agent"

System error 2 has occurred.

The system cannot find the file specified.

We launched the Tivoli Storage Manager Backup/Archive client interface and started the

restore of the deleted directories, shown in Figure 7-7.
