IBM TS7700 Release 5.3 Guide
by Larry Coyne, Yuki Asakura, Dave Brettell, Ramón A. Minjares Campos, Nielson ’Nino’ de Carvalho, Derek Erdmann, Rin Fujiwara, Nobuhiko Furuya, Lourie Goodall, Joe Hew, Kousei Kawamura, Tony Makepeace, Stefan Neff, Tomoaki Ogino, Shinya Ohri, Alberto Barajas Ortiz, Aderson Pacini, Trinidad Armando Rangel Ruiz, Michael Scott, Taisei Takai, Nao Takemura, Erina Tatsumi, Takahiro Tsuda, Shinsuke Ueyama, Chen Zhu
Overview
This IBM Redbooks® publication covers IBM TS7700 R5.3. The IBM TS7700 is part of a family of IBM Enterprise tape products. This book is intended for system architects and storage administrators who want to integrate their storage systems for optimal operation.
Building on over 25 years of experience, the R5.3 release includes many features that enable improved performance, usability, and security. Highlights include the IBM TS7700 Advanced Object Store, an all flash TS7770, grid resiliency enhancements, and Logical WORM retention.
By using the same hierarchical storage techniques, the TS7700 (TS7770 and TS7760) can also off load to object storage. Because object storage is cloud-based and accessible from different regions, the TS7700 Cloud Storage Tier support essentially allows the cloud to be an extension of the grid. As of this writing, the TS7700C supports the ability to off load to IBM Cloud Object Storage, Amazon S3, and RSTOR.
This publication explains features and concepts that are specific to the IBM TS7700 as of release R5.3. The R5.3 microcode level provides IBM TS7700 Cloud Storage Tier enhancements, IBM DS8000 Object Storage enhancements, Management Interface dual control security, and other smaller enhancements. The R5.3 microcode level can be installed on the IBM TS7770 and IBM TS7760 models only.
TS7700 provides tape virtualization for the IBM Z® environment. Off loading to physical tape behind a TS7700 is used by hundreds of organizations around the world.
New and existing capabilities of the TS7700 5.3 release includes the following highlights:
- Support for IBM TS1160 Tape Drives and JE/JM media
- Eight-way Grid Cloud, which consists of up to three generations of TS7700
- Synchronous and asynchronous replication of virtual tape and TCT objects
- Grid access to all logical volume and object data independent of where it resides
- An all flash TS7770 option for improved performance
- Full Advanced Object Store Grid Cloud support of DS8000 Transparent Cloud Tier
- Full AES256 encryption for data that is in-flight and at-rest
- Tight integration with IBM Z and DFSMS policy management
- DS8000 Object Store with AES256 in-flight encryption and compression
- Regulatory compliance through Logical WORM and LWORM Retention support
- Cloud Storage Tier support for archive, logical volume versions, and disaster recovery
- Optional integration with physical tape
- 16 Gb IBM FICON® throughput that exceeds 4 GBps per TS7700 cluster
- Grid Resiliency Support with Control Unit Initiated Reconfiguration (CUIR) support
- IBM Z hosts view up to 3,968 3490 devices per TS7700 grid
- TS7770 Cache On Demand feature that uses capacity-based licensing
- TS7770 support of SSD within the VED server
The TS7700T writes data by policy to physical tape through attachment to high-capacity, high-performance IBM TS1160, IBM TS1150, and IBM TS1140 tape drives that are installed in an IBM TS4500 or TS3500 tape library.
The TS7770 models are based on high-performance and redundant IBM Power9® technology. They provide improved performance for most IBM Z tape workloads when compared to the previous generations of IBM TS7700.
