Seize fine-grained control of when and where your users can access your system.
In traditional Unix authentication there is not much granularity available in limiting a user’s ability to log in. For example, how would you limit the hosts that users can come from when logging into your servers? Your first thought might be to set up TCP wrappers or possibly firewall rules [Hack #33] and [Hack #34] . But what if you wanted to allow some users to log in from a specific host, but disallow others from logging in from it? Or what if you wanted to prevent some users from logging in at certain times of the day because of daily maintenance, but allow others (i.e., administrators) to log in at any time they wish? To get this working with every service that might be running on your system, you would traditionally have to patch each of them to support this new functionality. This is where PAM enters the picture.
PAM, or pluggable authentication modules, allows for just this sort of functionality (and more) without the need to patch all of your services. PAM has been available for quite some time under Linux, FreeBSD, and Solaris, and is now a standard component of the traditional authentication facilities on these platforms. Many services that need to use some sort of authentication now support PAM.
Modules are configured for services in a
stack, with the authentication process
proceeding from top to bottom as the access checks complete
successfully. You can build a custom stack for any service by
creating a file in /etc/pam.d
with the same name
as the service. If you need even more granularity, an entire stack of
modules can be included by using the
pam_stack
module. This allows you to specify
another external file containing a stack. If a service does not have
its own configuration file in /etc/pam.d
, it
will default to using the stack specified in
/etc/pam.d/other
.
When configuring a service for use with PAM, there are several types
of entries available. These types allow one to specify whether a
module provides authentication, access control, password change
control, or session setup and teardown. Right now, we are interested
in only one of the types: the account type. This entry type allows
you to specify modules that will control access to accounts that have
been authenticated. In addition to the service-specific configuration
files, some modules have extended configuration information that can
be specified in files within the /etc/security
directory. For this hack, we’ll mainly use two of
the most useful modules of this type,
pam_access
and pam_time
.
The pam_access
module allows one to limit where a
user or group of users may log in from. To make use of it,
you’ll first need to configure the service you wish
to use the module with. You can do this by editing the
service’s PAM config file in
/etc/pam.d
.
Here’s an example of what
/etc/pam.d/login
might look like under Red Hat
9:
#%PAM-1.0 auth required pam_securetty.so auth required pam_stack.so service=system-auth auth required pam_nologin.so account required pam_stack.so service=system-auth password required pam_stack.so service=system-auth session required pam_stack.so service=system-auth session optional pam_console.so
Notice the use of the pam_stack
module—it
includes the stack contained within the
system-auth
file. Let’s see
what’s inside
/etc/pam.d/system-auth
:
#%PAM-1.0 # This file is auto-generated. # User changes will be destroyed the next time authconfig is run. auth required /lib/security/$ISA/pam_env.so auth sufficient /lib/security/$ISA/pam_unix.so likeauth nullok auth required /lib/security/$ISA/pam_deny.so account required /lib/security/$ISA/pam_unix.so password required /lib/security/$ISA/pam_cracklib.so retry=3 type= password sufficient /lib/security/$ISA/pam_unix.so nullok use_authtok md5 shadow password required /lib/security/$ISA/pam_deny.so session required /lib/security/$ISA/pam_limits.so session required /lib/security/$ISA/pam_unix.so
To add the pam_access
module to the login service,
you could add another account entry to the login configuration file,
which would, of course, just enable the module for the login service.
Alternatively, you could add the module to the
system-auth
file, which would enable it for most
of the PAM-aware services on the system.
To add pam_access
to the login service (or any
other service for that matter), simply add a line like this to the
service’s configuration file after any preexisting
account entries:
account required pam_access.so
Now that we’ve enabled the
pam_access
module for our services, we can edit
/etc/security/access.conf
to control how the
module behaves. Each entry in the file can specify multiple users,
groups, and hostnames to which the entry applies, and specify whether
it’s allowing or disallowing remote or local access.
When pam_access
is invoked by an entry in a
service configuration file, it will look through the lines of
access.conf
and stop at the first match it
finds. Thus, if you want to create default entries to fall back on,
you’ll want to put the more specific entries first,
with the general entries following them.
The general form of an entry in access.conf
is:
permission : users : origins
where permission
can be either a
+
or -
. This denotes whether
the rule grants or denies access, respectively.
The users
portion allows you to specify a
list of users or groups, separated by whitespace. In addition to
simply listing users in this portion of the entry, you can use the
form
user
@
host
,
where host
is the local hostname of the
machine being logged into. This allows you to use a single
configuration file across multiple machines, but still specify rules
pertaining to specific machines. The
origins
portion is compared against the
origin of the access attempt. Hostnames can be used for remote
origins, and the special LOCAL
keyword can be used
for local access. Instead of explicitly specifying users, groups, or
origins, you can also use the ALL
and
EXCEPT
keywords to perform set operations on any
of the lists.
Here’s a simple example of locking out the user
andrew (Eep! That’s me!) from a host named
colossus
:
- : andrew : colossus
Note that if a group that shares its name with a user is specified, the module will interpret the rule as applying to both the user and the group.
Now that we’ve covered
how to limit where a user may log in from and how to set up a PAM
module, let’s take a look at how to limit what time
a user may log in by using the pam_time
module. To
configure this module, you need to edit
/etc/security/time.conf
. The format for the
entries in this file are a little more flexible than that of
access.conf
, thanks to the availability of the
NOT (!
), AND (&
), and OR
(|
) operators.
The general form for an entry in time.conf
is:
services
;devices
;users
;times
The services
portion of the entry
specifies what PAM-enabled service will be regulated. You can usually
get a full list of the available services by looking at the contents
of your /etc/pam.d
directory.
For instance, here’s the
contents of
/etc/pam.d
on a RedHat Linux system:
$ ls -1 /etc/pam.d
authconfig
chfn
chsh
halt
internet-druid
kbdrate
login
neat
other
passwd
poweroff
ppp
reboot
redhat-config-mouse
redhat-config-network
redhat-config-network-cmd
redhat-config-network-druid
rhn_register
setup
smtp
sshd
su
sudo
system-auth
up2date
up2date-config
up2date-nox
vlock
To set up pam_time
for use with any of these
services, you’ll need to add a line like this to the
file in /etc/pam.d
that corresponds to the
service that you want to regulate:
account required /lib/security/$ISA/pam_time.so
The devices
portion specifies the terminal
device that the service is being accessed from. For console logins,
you can use !ttyp*
, which specifies all TTY
devices except for pseudo TTYs. If you want the entry to only affect
remote logins, then use ttyp*
. You can restrict it
to all users (console, remote, and X11) by using
tty*
.
For the users
portion of the entry, you can
specify a single user or a list of users by separating each one with
a |
character. The times
portion is used to specify the times that the rule will apply. Each
time range is specified with a combination of two character
abbreviations, which denote the days that the rule will apply,
followed with a range of hours for that day. The abbreviations for
the days of the week are Mo
,
Tu
, We
, Th
,
Fr
, Sa
, and
Su
. For convenience you can use
Wk
to specify weekdays and Wd
to specify the weekend. In addition, you can use
Al
to specify every day of the week. These last
three basically expand to the set of days that compose each time
period. This is important to remember, since repeated days are
subtracted from the set of days that the rule will apply to (e.g.,
WkSu
would effectively be just
Sa
). The range of hours is simply specified as two
24-hour times, minus the colons, separated by a dash (e.g., 0630-1345
is 6:30 A.M. to 1:45 P.M.).
If you wanted to disallow access to the user andrew from the local console on weekends and during the week after hours, you could use an entry like this:
system-auth;!ttyp*;andrew;Wk1700-0800|Wd0000-2400
Or perhaps you want to limit remote logins through SSH during a system maintenance window lasting from 7 P.M. Friday to 7 A.M. Saturday, but want to allow a sysadmin to log in:
sshd;ttyp*;!andrew;Fr1900-0700
As you can see, there’s a lot of flexibility for
creating entries, thanks to the logical Boolean operators that are
available. Just make sure that you remember to configure the service
file in /etc/pam.d
for use with
pam_time
when you create entries
in
/etc/security/time.conf
.
