Setting up smart wearable

The first thing to note about the hardware setup is that it is big and bulky. This is only a POC and is not even a remotely close production setup. The hardware setup would consist of an accelerometer connected to Raspberry Pi 3 and a 16X2 LCD.

The accelerometer ADXL345 gives the acceleration of X, Y, and Z axis over I2C protocol.

Connect the hardware as follows:

As you can see in the preceding schematic, we have made the following connections:

  • Raspberry Pi and LCD:

Raspberry Pi number - Pin name

16x2 LCD Pi name

6 - GND - Breadboard rail 1

1 - GND

2 - 5V - Breadboard rail 2

2 - VCC

1 k Ohm ...
