9.1 Overview

This example uses the FBIIPLRE PL/I example from the Application Monitor IVP, and

monitors its execution using option 2 of the primary option menu - Analyze a Specified Job.

9.2 Setting the defaults

Setting the defaults for this example is much simpler than for the COBOL example given in

“Application Monitor and COBOL” on page 241. This is because the Analyze a Specified Job

panel allows you to specify all the “default” values except the language listing data sets. So

the only thing we need to set in the default panels is the PL/I listing data set.

1. To do this, we select option 6 to get to the Default menu as shown in Figure 9-1.

Figure 9-1 Selecting the defaults menu

Chapter 9. Application Monitor and PL/I 259

2. Then we select option 2 to get to the Default Data Set Name panel as shown in Figure 9-2.

Figure 9-2 Selecting the Default Data Set Names panel

3. At the default data set name panel, we quickly fill out our PL/I listing data set name.

4. Select option 3 because we wish to save the data as shown in Figure 9-3.

5. Press the Enter key to trigger the actual saving.

Figure 9-3 Saving the PL/I listing data set name
