Kapitel 6
Ansichten, Pläne und Plot
226
Mit dem Plotbefehl DATEI|DRUCKEN|DRUCKEN müssen Sie dann nur noch die
Planansicht auswählen (Abbildung 6.41). Sie können hier auch mehrere Ansich-
ten auswählen und diese Auswahl als Plansatz für wiederholtes Plotten speichern.
Abb. 6.41: Plotausgabe mit Auswahl der Ansicht
6.6 Übungsfragen
1. Wo liegt die normale Schnitthöhe in den Grundrissen?
2. Wo ist sie definiert?
3. Welche Bedeutung hat der Z
USCHNEIDEBEREICH eines Grundrisses?
4. Wozu braucht man Deckenpläne?
5. Was generiert man mit 3D-S
CHNITTBEREICH?
6. Womit erstellen Sie eigene Ansichten?
7. Wie wird ein S
CHNITT mit Knick erstellt?
8. Was ist der Unterschi ...
