Chapter 3. NODAL AND LOOP ANALYSIS TECHNIQUES

THE LEARNING GOALS FOR THIS CHAPTER ARE:

• Be able to calculate all currents and voltages in circuits that contain multiple nodes and loops

• Learn to employ Kirchhoff's current law (KCL) to perform a nodal analysis to determine all the node voltages in a circuit

• Learn to employ Kirchhoff's voltage law (KVL) to perform a loop analysis to determine all the loop currents in a network

• Be able to ascertain which of the two analysis techniques should be utilized to solve a particular problem

Boeing Dreamliner Truly a dream come true, the Boeing 787 Dreamliner brings big-jet ranges to mid-size airplanes. A pleasure for both cross-country and intercontinental commercial travelers, this super-efficient airplane can carry 210 to 330 passengers on long-range flights from nearly 3,000 miles to over 9,000 miles. Featuring composite materials, it boasts unmatched efficiency, requiring 20% less fuel than its competitors. In various design stages for nearly six years, the final assembly plant opened in 2007 in Washington State and first flight occurred in late 2009.

Inside its efficient hull lies state of the art electronics. Based on an open architecture, the Dreamliner has health-monitoring systems that allow the airplane to self-monitor and report maintenance requirements to ground computer systems. A wireless broadband link sends this real-time diagnostic ...
