第 9 章 微前端的后端模式 微前端的后端模式

本作品已使用人工智能进行翻译。欢迎您提供反馈和意见:translation-feedback@oreilly.com

你可能会认为,微前端只有在与微服务相结合时才可能是 ,因为我们可以拥有端到端的技术自主权。也许你会认为,你的单体架构永远不会支持微前端,甚至认为在 API 层上采用单体就意味着在前端也要照搬架构。 但事实并非如此。有几个细微差别需要考虑,微前端绝对可以与微服务和单体结合使用。

在本章中,我们将回顾前端层和后端层之间的一些可能集成。尤其是,我们将分析微前端如何与单体、微服务,甚至与后端换前端(BFF)模式结合使用。

此外,我们还将讨论与不同微前端实现集成的最佳模式,如垂直拆分、与客户端组合的水平拆分以及与服务器端组合的水平拆分。

最后,我们将探讨 GraphQL 如何作为 API 的单一入口,成为微前端的有效解决方案。

API 集成和微前端

让我们先来定义一下我们可能在网络应用中使用的不同 API 方法。如图 9-1 所示,我们将重点关注最常用和最著名的模式。

但这并不意味着微前端只能使用这些实现。例如,您可以为 WebSocket(通过单个 TCP 连接的双向计算机通信协议)或超媒体选择合适的方法。在超媒体的情况下--例如,在响应内容中使用带有超媒体链接的 REST--消费 API 的客户端可以通过遍历这些链接动态导航到相应的资源。关键是要学会如何使用 BFF、API 网关或服务字典模式。

Diagram illustrating micro-frontends with server-side and client-side compositions using backend-for-frontend, API gateway, or service dictionary patterns, highlighting vertical and horizontal splits.
图 9-1. 微前端和 API 层

本章我们将分析三种模式:

服务字典

服务字典只是供客户端使用的服务列表。它主要是在我们用单体或模块化单体架构开发 API 层时使用;不过,它也可以用带 API 网关的微服务架构等其他架构来实现。服务字典避免了在持续集成(CI)过程中创建共享库、定义环境变量或注入配置的需要,也消除了对前端代码库中所有端点进行硬编码的要求。当微前端加载时,字典会首次加载,允许客户端直接从服务字典中检索要使用的 URL。

API 网关

众所周知,在微服务社区,API 网关是微服务架构的单一入口。客户端可以通过一个网关使用微服务内部开发的 API。API 网关还能实现一系列功能的集中化:

  • 令牌验证,需要在将请求传递给微服务之前验证令牌的签名
  • 可视性和报告,我们有一个集中的手段来验证所有入站和出站流量
  • 速率限制:API 网关会在超过特定阈值后拒绝请求,例如,将来自客户端的请求设置为每秒 100 个,因此当超过阈值时,API 网关会返回错误,而不是调用微服务来满足请求。
BFF

BFF 是 API 网关模式的扩展,为每种客户类型创建了一个单一入口。例如,我们可以为网络应用程序建立一个 BFF,为移动设备建立另一个 BFF,为我们正在商业化的物联网(IoT)设备建立第三个 BFF。BFF 减少了客户端和服务器之间的对话,聚合 API 响应并返回一个简单的数据结构,供客户端解析并在用户界面内呈现。这样就能在很大程度上自由塑造专用于客户端的 API,并减少客户端与后端层之间的往返次数。

这些模式也不是相互排斥的,它们可以组合在一起工作。

值得一提的另一种可能性是为客户端编写 API 端点库。不过,我不鼓励在微前端中采用这种做法,因为我们有可能在某些微前端中嵌入较旧版本的库,因此,用户界面可能会出现一些问题,比如信息过时,甚至由于某些 ...
