Chapter 4. Pattern Matching with Regular Expressions


Suppose you have been on the Internet for a few years and have been very faithful about saving all your correspondence, just in case you (or your lawyers, or the prosecution) need a copy. The result is that you have a 5 GB disk partition dedicated to saved mail. And let’s further suppose that you remember that somewhere in there is an email message from someone named Angie or Anjie. Or was it Angy? But you don’t remember what you called it or where you stored it. Obviously, you have to look for it.

But while some of you go and try to open up all 15,000,000 documents in a word processor, I’ll just find it with one simple command. Any system that provides regular expression support allows me to search for the pattern in several ways. The simplest to understand is:


which you can probably guess means just to search for any of the variations. A more concise form (“more thinking, less typing”) is:

An[^  dn]

The syntax will become clear as we go through this chapter. Briefly, the “A” and the “n” match themselves, in effect finding words that begin with “An”, while the cryptic [^ dn] requires the “An” to be followed by a character other than (^ means not in this context) a space (to eliminate the very common English word “an” at the start of a sentence) or “d” (to eliminate the common word “and”) or “n” (to eliminate Anne, Announcing, etc.). Has your word processor gotten past its splash screen yet? Well, it doesn’t matter, because I’ve already found the missing file. To find the answer, I just typed the command:

grep 'An[^ dn]' *

Regular expressions, or regexes for short, provide a concise and precise specification of patterns to be matched in text.

As another example of the power of regular expressions, consider the problem of bulk-updating hundreds of files. When I started with Java, the syntax for declaring array references was baseType arrayVariableName[]. For example, a method with an array argument, such as every program’s main method, was commonly written as:

public static void main(String args[]) {

But as time went by, it became clear to the stewards of the Java language that it would be better to write it as baseType[] arrayVariableName. For example:

public static void main(String[] args) {

This is better Java style because it associates the “array-ness” of the type with the type itself, rather than with the local argument name, and the compiler now accepts both modes. I wanted to change all occurrences of main written the old way to the new way. I used the pattern main(String [a-z] with the grep utility described earlier to find the names of all the files containing old-style main declarations (i.e., main(String followed by a space and a name character rather than an open square bracket). I then used another regex-based Unix tool, the stream editor sed, in a little shell script to change all occurrences in those files from main(String *([a-z][a-z]*)[] to main(String[] $1 (the syntax used here is discussed later in this chapter). Again, the regex-based approach was orders of magnitude faster than doing it interactively, even using a reasonably powerful editor such as vi or emacs, let alone trying to use a graphical word processor.

Historically, the syntax of regexes has changed as they get incorporated into more tools and more languages, so the exact syntax in the previous examples is not exactly what you’d use in Java, but it does convey the conciseness and power of the regex mechanism.[17]

As a third example, consider parsing an Apache web server logfile, where some fields are delimited with quotes, others with square brackets, and others with spaces. Writing ad-hoc code to parse this is messy in any language, but a well-crafted regex can break the line into all its constituent fields in one operation (this example is developed in Program: Apache Logfile Parsing).

These same time gains can be had by Java developers. Regular expression support has been in the standard Java runtime for ages and is well integrated (e.g., there are regex methods in the standard class java.lang.String and in the “new I/O” package). There are a few other regex packages for Java, and you may occasionally encounter code using them, but pretty well all code from this century can be expected to use the built-in package. The syntax of Java regexes themselves is discussed in Regular Expression Syntax, and the syntax of the Java API for using regexes is described in Using regexes in Java: Test for a Pattern. The remaining recipes show some applications of regex technology in Java.

See Also

Mastering Regular Expressions by Jeffrey Friedl (O’Reilly) is the definitive guide to all the details of regular expressions. Most introductory books on Unix and Perl include some discussion of regexes; Unix Power Tools devotes a chapter to them.

Regular Expression Syntax


You need to learn the syntax of Java regular expressions.


Consult Table 4-1 for a list of the regular expression characters.


These pattern characters let you specify regexes of considerable power. In building patterns, you can use any combination of ordinary text and the metacharacters, or special characters, in Table 4-1. These can all be used in any combination that makes sense. For example, a+ means any number of occurrences of the letter a, from one up to a million or a gazillion. The pattern Mrs?\. matches Mr. or Mrs. And .* means “any character, any number of times,” and is similar in meaning to most command-line interpreters’ meaning of the \* alone. The pattern \d+ means any number of numeric digits. \d{2,3} means a two- or three-digit number.

Table 4-1. Regular expression metacharacter syntax



Start of line/string


End of line/string


Word boundary


Not a word boundary


Beginning of entire string


End of entire string


End of entire string (except allowable final line terminator)

See Matching Newlines in Text


Any one character (except line terminator)


“Character class”; any one character from those listed


Any one character not from those listed

See Using regexes in Java: Test for a Pattern

Alternation and Grouping


Grouping (capture groups)

See Finding the Matching Text



(?:_re_ )

Noncapturing parenthesis


End of the previous match

\ n

Back-reference to capture group number "n"

Normal (greedy) quantifiers

{ m,n }

Quantifier for “from m to n repetitions”

See Replacing the Matched Text

{ m ,}

Quantifier for "m or more repetitions”

{ m }

Quantifier for “exactly m repetitions”

See Program: Apache Logfile Parsing

{,n }

Quantifier for 0 up to n repetitions


Quantifier for 0 or more repetitions

Short for {0,}


Quantifier for 1 or more repetitions

Short for {1,}; see Using regexes in Java: Test for a Pattern


Quantifier for 0 or 1 repetitions (i.e., present exactly once, or not at all)

Short for {0,1}

Reluctant (non-greedy) quantifiers

{ m,n }?

Reluctant quantifier for “from m to n repetitions”

{ m ,}?

Reluctant quantifier for "m or more repetitions”

{,n }?

Reluctant quantifier for 0 up to n repetitions


Reluctant quantifier: 0 or more


Reluctant quantifier: 1 or more

See Program: Apache Logfile Parsing


Reluctant quantifier: 0 or 1 times

Possessive (very greedy) quantifiers

{ m,n }+

Possessive quantifier for “from m to n repetitions”

{ m ,}+

Possessive quantifier for "m or more repetitions”

{,n }+

Possessive quantifier for 0 up to n repetitions


Possessive quantifier: 0 or more


Possessive quantifier: 1 or more


Possessive quantifier: 0 or 1 times

Escapes and shorthands


Escape (quote) character: turns most metacharacters off; turns subsequent alphabetic into metacharacters


Escape (quote) all characters up to \E


Ends quoting begun with \Q


Tab character


Return (carriage return) character


Newline character

See Matching Newlines in Text


Form feed


Character in a word

Use \w+ for a word; see Program: Apache Logfile Parsing


A nonword character


Numeric digit

Use \d+ for an integer; see Using regexes in Java: Test for a Pattern


A nondigit character



Space, tab, etc., as determined by java.lang.Character.isWhitespace()


A nonwhitespace character

See Program: Apache Logfile Parsing

Unicode blocks (representative samples)


A character in the Greek block

(Simple block)


Any character not in the Greek block


An uppercase letter

(Simple category)


A currency symbol

POSIX-style character classes (defined only for US-ASCII)


Alphanumeric characters



Alphabetic characters



Any ASCII character



Space and tab characters


Space characters

[ \t\n\x0B\f\r]


Control characters



Numeric digit characters



Printable and visible characters (not spaces or control characters)


Printable characters


Punctuation characters

One of !"#$%&'()\*+,-./:;<=>?@[]\^_`{|}\~


Lowercase characters



Uppercase characters



Hexadecimal digit characters


Regexes match anyplace possible in the string. Patterns followed by greedy quantifiers (the only type that existed in traditional Unix regexes) consume (match) as much as possible without compromising any subexpressions that follow; patterns followed by possessive quantifiers match as much as possible without regard to following subexpressions; patterns followed by reluctant quantifiers consume as few characters as possible to still get a match.

Also, unlike regex packages in some other languages, the Java regex package was designed to handle Unicode characters from the beginning. And the standard Java escape sequence \u nnnn is used to specify a Unicode character in the pattern. We use methods of java.lang.Character to determine Unicode character properties, such as whether a given character is a space. Again, note that the backslash must be doubled if this is in a Java string that is being compiled because the compiler would otherwise parse this as “backslash-u” followed by some numbers.

To help you learn how regexes work, I provide a little program called REDemo.[18] The code for REDemo is too long to include in the book; in the online directory regex of the darwinsys-api repo, you will find, which you can run to explore how regexes work.

In the uppermost text box (see Figure 4-1), type the regex pattern you want to test. Note that as you type each character, the regex is checked for syntax; if the syntax is OK, you see a checkmark beside it. You can then select Match, Find, or Find All. Match means that the entire string must match the regex, and Find means the regex must be found somewhere in the string (Find All counts the number of occurrences that are found). Below that, you type a string that the regex is to match against. Experiment to your heart’s content. When you have the regex the way you want it, you can paste it into your Java program. You’ll need to escape (backslash) any characters that are treated specially by both the Java compiler and the Java regex package, such as the backslash itself, double quotes, and others (see the following sidebar). Once you get a regex the way you want it, there is a “Copy” button (not shown in these screenshots) to export the regex to the clipboard, with or without backslash doubling depending on how you want to use it.

In Figure 4-1, I typed qu into the REDemo program’s Pattern box, which is a syntactically valid regex pattern: any ordinary characters stand as regexes for themselves, so this looks for the letter q followed by u. In the top version, I typed only a q into the string, which is not matched. In the second, I have typed quack and the q of a second quack. Because I have selected Find All, the count shows one match. As soon as I type the second u, the count is updated to two, as shown in the third version.

Regexes can do far more than just character matching. For example, the two-character regex ^T would match beginning of line (^) immediately followed by a capital T—that is, any line beginning with a capital T. It doesn’t matter whether the line begins with Tiny trumpets, Titanic tubas, or Triumphant twisted trombones, as long as the capital T is present in the first position.

But here we’re not very far ahead. Have we really invested all this effort in regex technology just to be able to do what we could already do with the java.lang.String method startsWith()? Hmmm, I can hear some of you getting a bit restless. Stay in your seats! What if you wanted to match not only a letter T in the first position, but also a vowel (a, e, i, o, or u) immediately after it, followed by any number of letters in a word, followed by an exclamation point? Surely you could do this in Java by checking startsWith("T") and charAt(1) == 'a' || charAt(1) == 'e', and so on? Yes, but by the time you did that, you’d have written a lot of very highly specialized code that you couldn’t use in any other application. With regular expressions, you can just give the pattern ^T[aeiou]\w*!. That is, ^ and T as before, followed by a character class listing the vowels, followed by any number of word characters (\w*), followed by the exclamation point.

REDemo with simple examples
Figure 4-1. REDemo with simple examples

“But wait, there’s more!” as my late, great boss Yuri Rubinsky used to say. What if you want to be able to change the pattern you’re looking for at runtime? Remember all that Java code you just wrote to match T in column 1, plus a vowel, some word characters, and an exclamation point? Well, it’s time to throw it out. Because this morning we need to match Q, followed by a letter other than u, followed by a number of digits, followed by a period. While some of you start writing a new function to do that, the rest of us will just saunter over to the RegEx Bar & Grille, order a ^Q[^u]\d+\.. from the bartender, and be on our way.

OK, the [^u] means match any one character that is not the character u. The \d+ means one or more numeric digits. The + is a quantifier meaning one or more occurrences of what it follows, and \d is any one numeric digit. So \d+ means a number with one, two, or more digits. Finally, the \.? Well, . by itself is a metacharacter. Most single metacharacters are switched off by preceding them with an escape character. Not the Esc key on your keyboard, of course. The regex “escape” character is the backslash. Preceding a metacharacter like . with this escape turns off its special meaning, so we look for a literal period rather than “any character.” Preceding a few selected alphabetic characters (e.g., n, r, t, s, w) with escape turns them into metacharacters. Figure 4-2 shows the Q[u]\d\..+ regex in action. In the first frame, I have typed part of the regex as Q[u and because there is an unclosed square bracket, the Syntax OK flag is turned off; when I complete the regex, it will be turned back on. In the second frame, I have finished typing the regex, and typed the data string as QA577 (which you should expect to match the ^Q[^u]\d+, but not the period since I haven’t typed it). In the third frame, I’ve typed the period so the Matches flag is set to Yes.

REDemo with “Q not followed by u” example
Figure 4-2. REDemo with “Q not followed by u” example

One good way to think of regular expressions is as a “little language” for matching patterns of characters in text contained in strings. Give yourself extra points if you’ve already recognized this as the design pattern known as Interpreter. A regular expression API is an interpreter for matching regular expressions.

So now you should have at least a basic grasp of how regexes work in practice. The rest of this chapter gives more examples and explains some of the more powerful topics, such as capture groups. As for how regexes work in theory—and there are a lot of theoretical details and differences among regex flavors—the interested reader is referred to in Mastering Regular Expressions. Meanwhile, let’s start learning how to write Java programs that use regular expressions.

Using regexes in Java: Test for a Pattern


You’re ready to get started using regular expression processing to beef up your Java code by testing to see if a given pattern can match in a given string.


Use the Java Regular Expressions Package, java.util.regex.


The good news is that the Java API for regexes is actually easy to use. If all you need is to find out whether a given regex matches a string, you can use the convenient boolean matches() method of the String class, which accepts a regex pattern in String form as its argument:

if (inputString.matches(stringRegexPattern)) {
    // it matched... do something with it...

This is, however, a convenience routine, and convenience always comes at a price. If the regex is going to be used more than once or twice in a program, it is more efficient to construct and use a Pattern and its Matcher(s). A complete program constructing a Pattern and using it to match is shown here:

public class RESimple {
    public static void main(String[] argv) {
        String pattern = "^Q[^u]\\d+\\.";
        String[] input = {
            "QA777. is the next flight. It is on time.",
            "Quack, Quack, Quack!"

        Pattern p = Pattern.compile(pattern);

        for (String in : input) {
            boolean found = p.matcher(in).lookingAt();

            System.out.println("'" + pattern + "'" +
            (found ? " matches '" : " doesn't match '") + in + "'");

The java.util.regex package consists of two classes, Pattern and Matcher, which provide the public API shown in Example 4-1.

Example 4-1. Regex public API
/** The main public API of the java.util.regex package.
 * Prepared by javap and Ian Darwin.

package java.util.regex;

public final class Pattern {
    // Flags values ('or' together)
    public static final int
    // No public constructors; use these Factory methods
    public static Pattern compile(String patt);
    public static Pattern compile(String patt, int flags);
    // Method to get a Matcher for this Pattern
    public Matcher matcher(CharSequence input);
    // Information methods
    public String pattern();
    public int flags();
    // Convenience methods
    public static boolean matches(String pattern, CharSequence input);
    public String[] split(CharSequence input);
    public String[] split(CharSequence input, int max);

public final class Matcher {
    // Action: find or match methods
    public boolean matches();
    public boolean find();
    public boolean find(int start);
    public boolean lookingAt();
    // "Information about the previous match" methods
    public int start();
    public int start(int whichGroup);
    public int end();
    public int end(int whichGroup);
    public int groupCount();
    public String group();
    public String group(int whichGroup);
    // Reset methods
    public Matcher reset();
    public Matcher reset(CharSequence newInput);
    // Replacement methods
    public Matcher appendReplacement(StringBuffer where, String newText);
    public StringBuffer appendTail(StringBuffer where);
    public String replaceAll(String newText);
    public String replaceFirst(String newText);
    // information methods
    public Pattern pattern();

/* String, showing only the RE-related methods */
public final class String {
    public boolean matches(String regex);
    public String replaceFirst(String regex, String newStr);
    public String replaceAll(String regex, String newStr);
    public String[] split(String regex);
    public String[] split(String regex, int max);

This API is large enough to require some explanation. The normal steps for regex matching in a production program are:

  1. Create a Pattern by calling the static method Pattern.compile() .
  2. Request a Matcher from the pattern by calling pattern.matcher(CharSequence) for each String (or other CharSequence) you wish to look through.
  3. Call (once or more) one of the finder methods (discussed later in this section) in the resulting Matcher.

The java.lang.CharSequence interface provides simple read-only access to objects containing a collection of characters. The standard implementations are String and StringBuffer/StringBuilder (described in Chapter 3), and the “new I/O” class java.nio.CharBuffer.

Of course, you can perform regex matching in other ways, such as using the convenience methods in Pattern or even in java.lang.String. For example:

public class StringConvenience {
    public static void main(String[] argv) {

        String pattern = ".*Q[^u]\\d+\\..*";
        String line = "Order QT300. Now!";
        if (line.matches(pattern)) {
            System.out.println(line + " matches \"" + pattern + "\"");
        } else {
            System.out.println("NO MATCH");

But the three-step list just described is the “standard” pattern for matching. You’d likely use the String convenience routine in a program that only used the regex once; if the regex were being used more than once, it is worth taking the time to “compile” it because the compiled version runs faster.

In addition, the Matcher has several finder methods, which provide more flexibility than the String convenience routine match(). The Matcher methods are:

Useda to compare the entire string against the pattern; this is the same as the routine in java.lang.String. Because it matches the entire String, I had to put .* before and after the pattern.
Used to match the pattern only at the beginning of the string.
Used to match the pattern in the string (not necessarily at the first character of the string), starting at the beginning of the string or, if the method was previously called and succeeded, at the first character not matched by the previous match.

Each of these methods returns boolean, with true meaning a match and false meaning no match. To check whether a given string matches a given pattern, you need only type something like the following:

Matcher m = Pattern.compile(patt).matcher(line);
if (m.find( )) {
    System.out.println(line + " matches " + patt)

But you may also want to extract the text that matched, which is the subject of the next recipe.

The following recipes cover uses of this API. Initially, the examples just use arguments of type String as the input source. Use of other CharSequence types is covered in Printing All Occurrences of a Pattern.

Finding the Matching Text


You need to find the text that the regex matched.


Sometimes you need to know more than just whether a regex matched a string. In editors and many other tools, you want to know exactly what characters were matched. Remember that with quantifiers such as *, the length of the text that was matched may have no relationship to the length of the pattern that matched it. Do not underestimate the mighty .*, which happily matches thousands or millions of characters if allowed to. As you saw in the previous recipe, you can find out whether a given match succeeds just by using find() or matches(). But in other applications, you will want to get the characters that the pattern matched.

After a successful call to one of the preceding methods, you can use these “information” methods to get information on the match:

start(), end()
Returns the character position in the string of the starting and ending characters that matched.
Returns the number of parenthesized capture groups, if any; returns 0 if no groups were used.
group(int i)
Returns the characters matched by group i of the current match, if i is greater than or equal to zero and less than or equal to the return value of groupCount(). Group 0 is the entire match, so group(0) (or just group()) returns the entire portion of the input that matched.

The notion of parentheses or “capture groups” is central to regex processing. Regexes may be nested to any level of complexity. The group(int) method lets you retrieve the characters that matched a given parenthesis group. If you haven’t used any explicit parens, you can just treat whatever matched as “level zero.” Example 4-2 shows part of

Example 4-2. Part of
public class REmatch {
    public static void main(String[] argv) {

        String patt = "Q[^u]\\d+\\.";
        Pattern r = Pattern.compile(patt);
        String line = "Order QT300. Now!";
        Matcher m = r.matcher(line);
        if (m.find()) {
            System.out.println(patt + " matches \"" +
                "\" in \"" + line + "\"");
        } else {
            System.out.println("NO MATCH");

When run, this prints:

Q[\^u]\d+\. matches "QT300." in "Order QT300. Now!"

An extended version of the REDemo program presented in Using regexes in Java: Test for a Pattern, called REDemo2, provides a display of all the capture groups in a given regex; one example is shown in Figure 4-3.

REDemo2 in action
Figure 4-3. REDemo2 in action

It is also possible to get the starting and ending indices and the length of the text that the pattern matched (remember that terms with quantifiers, such as the \d+ in this example, can match an arbitrary number of characters in the string). You can use these in conjunction with the String.substring() methods as follows:

        String patt = "Q[^u]\\d+\\.";
        Pattern r = Pattern.compile(patt);
        String line = "Order QT300. Now!";
        Matcher m = r.matcher(line);
        if (m.find()) {
            System.out.println(patt + " matches \"" +
                line.substring(m.start(0), m.end(0)) +
                "\" in \"" + line + "\"");
        } else {
            System.out.println("NO MATCH");

Suppose you need to extract several items from a string. If the input is:

Smith, John
Adams, John Quincy

and you want to get out:

John Smith
John Quincy Adams

just use:

public class REmatchTwoFields {
    public static void main(String[] args) {
        String inputLine = "Adams, John Quincy";
        // Construct an RE with parens to "grab" both field1 and field2
        Pattern r = Pattern.compile("(.*), (.*)");
        Matcher m = r.matcher(inputLine);
        if (!m.matches())
            throw new IllegalArgumentException("Bad input");
        System.out.println( + ' ' +;

Replacing the Matched Text

As we saw in the previous recipe, regex patterns involving quantifiers can match a lot of characters with very few metacharacters. We need a way to replace the text that the regex matched without changing other text before or after it. We could do this manually using the String method substring(). However, because it’s such a common requirement, the Java Regular Expression API provides some substitution methods. In all these methods, you pass in the replacement text or “righthand side” of the substitution (this term is historical: in a command-line text editor’s substitute command, the lefthand side is the pattern and the righthand side is the replacement text). The replacement methods are:

Replaces all occurrences that matched with the new string.
appendReplacement(StringBuffer, newString)
Copies up to before the first match, plus the given newString.
Appends text after the last match (normally used after appendReplacement).

Example 4-3 shows use of these three methods.

Example 4-3.
 * Quick demo of RE substitution: correct U.S. 'favor'
 * to Canadian/British 'favour', but not in "favorite"
 * @author Ian F. Darwin,
public class ReplaceDemo {
    public static void main(String[] argv) {

        // Make an RE pattern to match as a word only (\b=word boundary)
        String patt = "\\bfavor\\b";

        // A test input.
        String input = "Do me a favor? Fetch my favorite.";
        System.out.println("Input: " + input);

        // Run it from a RE instance and see that it works
        Pattern r = Pattern.compile(patt);
        Matcher m = r.matcher(input);
        System.out.println("ReplaceAll: " + m.replaceAll("favour"));

        // Show the appendReplacement method
        StringBuffer sb = new StringBuffer();
        System.out.print("Append methods: ");
        while (m.find()) {
            // Copy to before first match,
            // plus the word "favor"
            m.appendReplacement(sb, "favour");
        m.appendTail(sb);        // copy remainder

Sure enough, when you run it, it does what we expect:

Input: Do me a favor? Fetch my favorite.
ReplaceAll: Do me a favour? Fetch my favorite.
Append methods: Do me a favour? Fetch my favorite.

Printing All Occurrences of a Pattern


You need to find all the strings that match a given regex in one or more files or other sources.


This example reads through a file one line at a time. Whenever a match is found, I extract it from the line and print it.

This code takes the group() methods from Finding the Matching Text, the substring method from the CharacterIterator interface, and the match() method from the regex and simply puts them all together. I coded it to extract all the “names” from a given file; in running the program through itself, it prints the words import, java, until, regex, and so on, each on its own line:

C:\\> javac -d .
C:\\> java regex.ReaderIter

I interrupted it here to save paper. This can be written two ways: a traditional “line at a time” pattern shown in Example 4-4 and a more compact form using “new I/O” shown in Example 4-5 (the “new I/O” package is described in Chapter 10).

Example 4-4.
public class ReaderIter {
    public static void main(String[] args) throws IOException {
        // The RE pattern
        Pattern patt = Pattern.compile("[A-Za-z][a-z]+");
        // A FileReader (see the I/O chapter)
        BufferedReader r = new BufferedReader(new FileReader(args[0]));

        // For each line of input, try matching in it.
        String line;
        while ((line = r.readLine()) != null) {
            // For each match in the line, extract and print it.
            Matcher m = patt.matcher(line);
            while (m.find()) {
                // Simplest method:
                // System.out.println(;

                // Get the starting position of the text
                int start = m.start(0);
                // Get ending position
                int end = m.end(0);
                // Print whatever matched.
                // Use CharacterIterator.substring(offset, end);
                System.out.println(line.substring(start, end));
Example 4-5.
public class GrepNIO {
    public static void main(String[] args) throws IOException {

        if (args.length < 2) {
            System.err.println("Usage: GrepNIO patt file [...]");

        Pattern p=Pattern.compile(args[0]);
        for (int i=1; i<args.length; i++)
            process(p, args[i]);

    static void process(Pattern pattern, String fileName) throws IOException {

        // Get a FileChannel from the given file.
        FileChannel fc = new FileInputStream(fileName).getChannel();

        // Map the file's content
        ByteBuffer buf =, 0, fc.size());

        // Decode ByteBuffer into CharBuffer
        CharBuffer cbuf =

        Matcher m = pattern.matcher(cbuf);
        while (m.find()) {

The NIO version shown in Example 4-5 relies on the fact that an NIO Buffer can be used as a CharSequence. This program is more general in that the pattern argument is taken from the command-line argument. It prints the same output as the previous example if invoked with the pattern argument from the previous program on the command line:

java regex.GrepNIO "[A-Za-z][a-z]+"

You might think of using \w+ as the pattern; the only difference is that my pattern looks for well-formed capitalized words, whereas \w+ would include Java-centric oddities like theVariableName, which have capitals in nonstandard positions.

Also note that the NIO version will probably be more efficient because it doesn’t reset the Matcher to a new input source on each line of input as ReaderIter does.

Printing Lines Containing a Pattern


You need to look for lines matching a given regex in one or more files.


Write a simple grep-like program.


As I’ve mentioned, once you have a regex package, you can write a grep-like program. I gave an example of the Unix grep program earlier. grep is called with some optional arguments, followed by one required regular expression pattern, followed by an arbitrary number of filenames. It prints any line that contains the pattern, differing from Printing All Occurrences of a Pattern, which prints only the matching text itself. For example:

grep "[dD]arwin" *.txt

The preceding code searches for lines containing either darwin or Darwin in every line of every file whose name ends in .txt.[19] Example 4-6 is the source for the first version of a program to do this, called Grep0. It reads lines from the standard input and doesn’t take any optional arguments, but it handles the full set of regular expressions that the Pattern class implements (it is, therefore, not identical to the Unix programs of the same name). We haven’t covered the package for input and output yet (see Chapter 10), but our use of it here is simple enough that you can probably intuit it. The online source includes Grep1, which does the same thing but is better structured (and therefore longer). Later in this chapter, Program: Full Grep presents a JGrep program that uses my GetOpt (see Parsing Command-Line Arguments) to parse command-line options.

Example 4-6.
public class Grep0 {
    public static void main(String[] args) throws IOException {
        BufferedReader is =
            new BufferedReader(new InputStreamReader(;
        if (args.length != 1) {
            System.err.println("Usage: MatchLines pattern");
        Pattern patt = Pattern.compile(args[0]);
        Matcher matcher = patt.matcher("");
        String line = null;
        while ((line = is.readLine()) != null) {
            if (matcher.find()) {
                System.out.println("MATCH: " + line);

Controlling Case in Regular Expressions


You want to find text regardless of case.


Compile the Pattern passing in the flags argument Pattern.CASE_INSENSITIVE to indicate that matching should be case-independent (“fold” or ignore differences in case). If your code might run in different locales (see Chapter 15) then you should add Pattern.UNICODE_CASE. Without these flags, the default is normal, case-sensitive matching behavior. This flag (and others) are passed to the Pattern.compile() method, as in:

Pattern  reCaseInsens = Pattern.compile(pattern, Pattern.CASE_INSENSITIVE |
reCaseInsens.matches(input);        // will match case-insensitively

This flag must be passed when you create the Pattern; because Pattern objects are immutable, they cannot be changed once constructed.

The full source code for this example is online as

Matching “Accented” or Composite Characters


You want characters to match regardless of the form in which they are entered.


Compile the Pattern with the flags argument Pattern.CANON_EQ for “canonical equality.”


Composite characters can be entered in various forms. Consider, as a single example, the letter e with an acute accent. This character may be found in various forms in Unicode text, such as the single character é (Unicode character \u00e9) or as the two-character sequence (e followed by the Unicode combining acute accent, \u0301). To allow you to match such characters regardless of which of possibly multiple “fully decomposed” forms are used to enter them, the regex package has an option for “canonical matching,” which treats any of the forms as equivalent. This option is enabled by passing CANON_EQ as (one of) the flags in the second argument to Pattern.compile(). This program shows CANON_EQ being used to match several forms:

public class CanonEqDemo {
    public static void main(String[] args) {
        String pattStr = "\u00e9gal"; // egal
        String[] input = {
                "\u00e9gal", // egal - this one had better match :-)
                "e\u0301gal", // e + "Combining acute accent"
                "e\u02cagal", // e + "modifier letter acute accent"
                "e'gal", // e + single quote
                "e\u00b4gal", // e + Latin-1 "acute"
        Pattern pattern = Pattern.compile(pattStr, Pattern.CANON_EQ);
        for (int i = 0; i < input.length; i++) {
            if (pattern.matcher(input[i]).matches()) {
                    pattStr + " matches input " + input[i]);
            } else {
                    pattStr + " does not match input " + input[i]);

This program correctly matches the “combining accent” and rejects the other characters, some of which, unfortunately, look like the accent on a printer, but are not considered “combining accent” characters:

égal matches input égal
égal matches input e?gal
égal does not match input e?gal
égal does not match input e'gal
égal does not match input e´gal

For more details, see the character charts.

Matching Newlines in Text


You need to match newlines in text.


Use \n or \r.

See also the flags constant Pattern.MULTILINE, which makes newlines match as beginning-of-line and end-of-line (\^ and $).


Though line-oriented tools from Unix such as sed and grep match regular expressions one line at a time, not all tools do. The sam text editor from Bell Laboratories was the first interactive tool I know of to allow multiline regular expressions; the Perl scripting language followed shortly after. In the Java API, the newline character by default has no special significance. The BufferedReader method readLine() normally strips out whichever newline characters it finds. If you read in gobs of characters using some method other than readLine(), you may have some number of \n, \r, or \r\n sequences in your text string.[20] Normally all of these are treated as equivalent to \n. If you want only \n to match, use the UNIX_LINES flag to the Pattern.compile() method.

In Unix, ^ and $ are commonly used to match the beginning or end of a line, respectively. In this API, the regex metacharacters \^ and $ ignore line terminators and only match at the beginning and the end, respectively, of the entire string. However, if you pass the MULTILINE flag into Pattern.compile(), these expressions match just after or just before, respectively, a line terminator; $ also matches the very end of the string. Because the line ending is just an ordinary character, you can match it with . or similar expressions, and, if you want to know exactly where it is, \n or \r in the pattern match it as well. In other words, to this API, a newline character is just another character with no special significance. See the sidebar Pattern.compile() Flags. An example of newline matching is shown in Example 4-7.

Example 4-7.
public class NLMatch {
    public static void main(String[] argv) {

        String input = "I dream of engines\nmore engines, all day long";
        System.out.println("INPUT: " + input);

        String[] patt = {
            "engines.more engines",

        for (int i = 0; i < patt.length; i++) {
            System.out.println("PATTERN " + patt[i]);

            boolean found;
            Pattern p1l = Pattern.compile(patt[i]);
            found = p1l.matcher(input).find();
            System.out.println("DEFAULT match " + found);

            Pattern pml = Pattern.compile(patt[i],
            found = pml.matcher(input).find();
            System.out.println("MultiLine match " + found);

If you run this code, the first pattern (with the wildcard character .) always matches, whereas the second pattern (with $) matches only when MATCH_MULTILINE is set:

> java regex.NLMatch
INPUT: I dream of engines
more engines, all day long

PATTERN engines
more engines
DEFAULT match true
MULTILINE match: true

PATTERN engines$
DEFAULT match false
MULTILINE match: true

Program: Apache Logfile Parsing

The Apache web server is the world’s leading web server and has been for most of the Web’s history. It is one of the world’s best-known open source projects, and the first of many fostered by the Apache Foundation. But the name Apache is often claimed to be a pun on the origins of the server; its developers began with the free NCSA server and kept hacking at it or “patching” it until it did what they wanted. When it was sufficiently different from the original, a new name was needed. Because it was now “a patchy server,” the name Apache was chosen. Officialdom denies the story, but it’s cute anyway. One place actual patchiness does show through is in the logfile format. Consider Example 4-8.

Example 4-8. Apache log file excerpt - - [27/Oct/2000:09:27:09 -0400] "GET /java/javaResources.html
HTTP/1.0" 200 10450 "-" "Mozilla/4.6 [en] (X11; U; OpenBSD 2.8 i386; Nav)"

The file format was obviously designed for human inspection but not for easy parsing. The problem is that different delimiters are used: square brackets for the date, quotes for the request line, and spaces sprinkled all through. Consider trying to use a StringTokenizer; you might be able to get it working, but you’d spend a lot of time fiddling with it. However, this somewhat contorted regular expression[21] makes it easy to parse:

\^([\d.]+) (\S+) (\S+) \[([\w:/]+\s[+\-]\d{4})\] "(.+?)" (\d{3}) (\d+) "([\^"]+)"

You may find it informative to refer back to Table 4-1 and review the full syntax used here. Note in particular the use of the nongreedy quantifier +? in \"(.+?)\" to match a quoted string; you can’t just use .+ because that would match too much (up to the quote at the end of the line). Code to extract the various fields such as IP address, request, referrer URL, and browser version is shown in Example 4-9.

Example 4-9.
public class LogRegExp  {

    public static void main(String argv[]) {

        String logEntryPattern =
            "^([\\d.]+) (\\S+) (\\S+) \\[([\\w:/]+\\s[+-]\\d{4})\\] " +
            "\"(.+?)\" (\\d{3}) (\\d+) \"([^\"]+)\" \"([^\"]+)\"";

        System.out.println("RE Pattern:");

        System.out.println("Input line is:");
        String logEntryLine = LogExample.logEntryLine;

        Pattern p = Pattern.compile(logEntryPattern);
        Matcher matcher = p.matcher(logEntryLine);
        if (!matcher.matches() ||
            LogExample.NUM_FIELDS != matcher.groupCount()) {
            System.err.println("Bad log entry (or problem with regex):");
        System.out.println("IP Address: " +;
        System.out.println("UserName: " +;
        System.out.println("Date/Time: " +;
        System.out.println("Request: " +;
        System.out.println("Response: " +;
        System.out.println("Bytes Sent: " +;
        if (!"-"))
            System.out.println("Referer: " +;
        System.out.println("User-Agent: " +;

The implements clause is for an interface that just defines the input string; it was used in a demonstration to compare the regular expression mode with the use of a StringTokenizer. The source for both versions is in the online source for this chapter. Running the program against the sample input from Example 4-8 gives this output:

Using regex Pattern:
\^([\d.]+) (\S+) (\S+) \[([\w:/]+\s[+\-]\d{4})\] "(.+?)" (\d{3}) (\d+) "([\^"]+)"
Input line is: - - [27/Oct/2000:09:27:09 -0400] "GET /java/javaResources.html
HTTP/1.0" 200 10450 "-" "Mozilla/4.6 [en] (X11; U; OpenBSD 2.8 i386; Nav)"
IP Address:
Date&Time: 27/Oct/2000:09:27:09 -0400
Request: GET /java/javaResources.html HTTP/1.0
Response: 200
Bytes Sent: 10450
Browser: Mozilla/4.6 [en] (X11; U; OpenBSD 2.8 i386; Nav)

The program successfully parsed the entire logfile format with one call to matcher.matches().

Program: Data Mining

Suppose that I, as a published author, want to track how my book is selling in comparison to others. I can obtain this information for free just by clicking the page for my book on any of the major bookseller sites, reading the sales rank number off the screen, and typing the number into a file—but that’s too tedious. As I wrote in the book that this example looks for, “computers get paid to extract relevant information from files; people should not have to do such mundane tasks.” This program uses the Regular Expressions API and, in particular, newline matching to extract a value from an HTML page on the hypothetical QuickBookShops.web website. It also reads from a URL object (see REST Web Service Client). The pattern to look for is something like this (bear in mind that the HTML may change at any time, so I want to keep the pattern fairly general):

<b>QuickBookShop.web Sales Rank: </b>

Because the pattern may extend over more than one line, I read the entire web page from the URL into a single long string using my FileIO.readerToString() method (see Reading a File into a String) instead of the more traditional line-at-a-time paradigm. I then plot a graph using an external program (see Running an External Program from Java); this could (and should) be changed to use a Java graphics program (see Program: Grapher for some leads). The complete program is shown in Example 4-10.

Example 4-10.
public class BookRank {
    public final static String DATA_FILE = "book.sales";
    public final static String GRAPH_FILE = "book.png";
    public final static String PLOTTER_PROG = "/usr/local/bin/gnuplot";

    final static String isbn = "0596007019";
    final static String title = "Java Cookbook";

    /** Grab the sales rank off the web page and log it. */
    public static void main(String[] args) throws Exception {

        Properties p = new Properties();
        p.load(new FileInputStream(
            args.length == 0 ? "" : args[1]));
        String title = p.getProperty("title", "NO TITLE IN PROPERTIES");
        // The url must have the "isbn=" at the very end, or otherwise
        // be amenable to being string-catted to, like the default.
        String url = p.getProperty("url", "");
        // The 10-digit ISBN for the book.
        String isbn  = p.getProperty("isbn", "0000000000");
        // The RE pattern (MUST have ONE capture group for the number)
        String pattern = p.getProperty("pattern", "Rank: (\\d+)");

        int rank = getBookRank(isbn);

        System.out.println("Rank is " + rank);

        // Now try to draw the graph, using external
        // plotting program against all historical data.
        // Could use gnuplot, R, any other math/graph program.
        // Better yet: use one of the Java plotting APIs.

        PrintWriter pw = new PrintWriter(
            new FileWriter(DATA_FILE, true));
        String date = new SimpleDateFormat("MM dd hh mm ss yyyy ").
            format(new Date());
        pw.println(date + " " + rank);

        String gnuplot_cmd =
            "set term png\n" +
            "set output \"" + GRAPH_FILE + "\"\n" +
            "set xdata time\n" +
            "set ylabel \"Book sales rank\"\n" +
            "set bmargin 3\n" +
            "set logscale y\n" +
            "set yrange [1:60000] reverse\n" +
            "set timefmt \"%m %d %H %M %S %Y\"\n" +
            "plot \"" + DATA_FILE +
                "\" using 1:7 title \"" + title + "\" with lines\n"

        if (!new File(PLOTTER_PROG).exists()) {
            System.out.println("Plotting software not installed");
        Process proc = Runtime.getRuntime().exec(PLOTTER_PROG);
        PrintWriter gp = new PrintWriter(proc.getOutputStream());

     * Look for something like this in the HTML input:
     *     <b>Sales Rank:</b>
     *     #26,252
     *      </font><br>
     * @throws IOException
     * @throws IOException
    public static int getBookRank(String isbn) throws IOException {

        // The RE pattern - digits and commas allowed
        final String pattern = "Rank:</b> #([\\d,]+)";
        final Pattern r = Pattern.compile(pattern);

        // The url -- must have the "isbn=" at the very end, or otherwise
        // be amenable to being appended to.
        final String url = "" + isbn;

        // Open the URL and get a Reader from it.
        final BufferedReader is = new BufferedReader(new InputStreamReader(
            new URL(url).openStream()));

        // Read the URL looking for the rank information, as
        // a single long string, so can match RE across multi-lines.
        final String input = readerToString(is);

        // If found, append to sales data file.
        Matcher m = r.matcher(input);
        if (m.find()) {
            // Paren 1 is the digits (and maybe ','s) that matched; remove comma
            return Integer.parseInt(",",""));
        } else {
            throw new RuntimeException(
                "Pattern not matched in `" + url + "'!");

    private static String readerToString(BufferedReader is) throws IOException {
        StringBuilder sb = new StringBuilder();
        String line;
        while ((line = is.readLine()) != null) {
        return sb.toString();

Program: Full Grep

Now that we’ve seen how the regular expressions package works, it’s time to write JGrep, a full-blown version of the line-matching program with option parsing. Table 4-2 lists some typical command-line options that a Unix implementation of grep might include.

Table 4-2. Grep command-line options


Count only: don’t print lines, just count them


Context; print some lines above and below each line that matches (not implemented in this version; left as an exercise for the reader)

-f pattern

Take pattern from file named after -f instead of from command line


Suppress printing filename ahead of lines


Ignore case


List filenames only: don’t print lines, just the names they’re found in


Print line numbers before matching lines


Suppress printing certain error messages


Invert: print only lines that do NOT match the pattern

We discussed the GetOpt class in Parsing Command-Line Arguments. Here we use it to control the operation of an application program. As usual, because main() runs in a static context but our application main line does not, we could wind up passing a lot of information into the constructor. To save space, this version just uses global variables to track the settings from the command line. Unlike the Unix grep tool, this one does not yet handle “combined options,” so -l -r -i is OK, but -lri will fail, due to a limitation in the GetOpt parser used.

The program basically just reads lines, matches the pattern in them, and, if a match is found (or not found, with -v), prints the line (and optionally some other stuff, too). Having said all that, the code is shown in Example 4-11.

Example 4-11.
/** A command-line grep-like program. Accepts some command-line options,
 * and takes a pattern and a list of text files.
 * N.B. The current implementation of GetOpt does not allow combining short
 * arguments, so put spaces e.g., "JGrep -l -r -i pattern file..." is OK, but
 * "JGrep -lri pattern file..." will fail. Getopt will hopefully be fixed soon.
public class JGrep {
    private static final String USAGE =
        "Usage: JGrep pattern [-chilrsnv][-f pattfile][filename...]";
    /** The pattern we're looking for */
    protected Pattern pattern;
    /** The matcher for this pattern */
    protected Matcher matcher;
    private boolean debug;
    /** Are we to only count lines, instead of printing? */
    protected static boolean countOnly = false;
    /** Are we to ignore case? */
    protected static boolean ignoreCase = false;
    /** Are we to suppress printing of filenames? */
    protected static boolean dontPrintFileName = false;
    /** Are we to only list names of files that match? */
    protected static boolean listOnly = false;
    /** are we to print line numbers? */
    protected static boolean numbered = false;
    /** Are we to be silent about errors? */
    protected static boolean silent = false;
    /** are we to print only lines that DONT match? */
    protected static boolean inVert = false;
    /** Are we to process arguments recursively if directories? */
    protected static boolean recursive = false;

    /** Construct a Grep object for the pattern, and run it
     * on all input files listed in argv.
     * Be aware that a few of the command-line options are not
     * acted upon in this version - left as an exercise for the reader!
    public static void main(String[] argv) {

        if (argv.length < 1) {
        String patt = null;

        GetOpt go = new GetOpt("cf:hilnrRsv");

        char c;
        while ((c = go.getopt(argv)) != 0) {
            switch(c) {
                case 'c':
                    countOnly = true;
                case 'f':    /* External file contains the pattern */
                    try (BufferedReader b =
                        new BufferedReader(new FileReader(go.optarg()))) {
                        patt = b.readLine();
                    } catch (IOException e) {
                            "Can't read pattern file " + go.optarg());
                case 'h':
                    dontPrintFileName = true;
                case 'i':
                    ignoreCase = true;
                case 'l':
                    listOnly = true;
                case 'n':
                    numbered = true;
                case 'r':
                case 'R':
                    recursive = true;
                case 's':
                    silent = true;
                case 'v':
                    inVert = true;
                case '?':
                    System.err.println("Getopts was not happy!");

        int ix = go.getOptInd();

        if (patt == null)
            patt = argv[ix++];

        JGrep prog = null;
        try {
            prog = new JGrep(patt);
        } catch (PatternSyntaxException ex) {
            System.err.println("RE Syntax error in " + patt);

        if (argv.length == ix) {
            dontPrintFileName = true; // Don't print filenames if stdin
            if (recursive) {
                System.err.println("Warning: recursive search of stdin!");
            prog.process(new InputStreamReader(, null);
        } else {
            if (!dontPrintFileName)
                dontPrintFileName = ix == argv.length - 1; // Nor if only one file.
            if (recursive)
                dontPrintFileName = false;                // unless a directory!

            for (int i=ix; i<argv.length; i++) { // note starting index
                try {
                    prog.process(new File(argv[i]));
                } catch(Exception e) {

    /** Construct a JGrep object.
     * @param patt The pattern to look for
     * @param args the command-line options.
    public JGrep(String patt) throws PatternSyntaxException {
        if (debug) {
            System.err.printf("JGrep.JGrep(%s)%n", patt);
        // compile the regular expression
        int caseMode = ignoreCase ?
            Pattern.UNICODE_CASE | Pattern.CASE_INSENSITIVE :
        pattern = Pattern.compile(patt, caseMode);
        matcher = pattern.matcher("");

    /** Process one command line argument (file or directory)
     * @throws FileNotFoundException
    public void process(File file) throws FileNotFoundException {
        if (!file.exists() || !file.canRead()) {
                "ERROR: can't read file " + file.getAbsolutePath());
        if (file.isFile()) {
            process(new BufferedReader(new FileReader(file)),
        if (file.isDirectory()) {
            if (!recursive) {
                    "ERROR: -r not specified but directory given " +
            for (File nf : file.listFiles()) {
                process(nf);    // "Recursion, n.: See Recursion."
            "WEIRDNESS: neither file nor directory: " + file.getAbsolutePath());

    /** Do the work of scanning one file
     * @param    ifile    Reader    Reader object already open
     * @param    fileName String    Name of the input file
    public void process(Reader ifile, String fileName) {

        String inputLine;
        int matches = 0;

        try (BufferedReader reader = new BufferedReader(ifile)) {

            while ((inputLine = reader.readLine()) != null) {
                if (matcher.find()) {
                    if (listOnly) {
                        // -l, print filename on first match, and we're done
                    if (countOnly) {
                    } else {
                        if (!dontPrintFileName) {
                            System.out.print(fileName + ": ");
                } else if (inVert) {
            if (countOnly)
                System.out.println(matches + " matches in " + fileName);
        } catch (IOException e) {

[17] Non-Unix fans fear not, for you can use tools like grep on Windows systems using one of several packages. One is an open source package alternately called CygWin (after Cygnus Software) or GnuWin32. Another is Microsoft’s findstr command for Windows. Or you can use my Grep program in Printing Lines Containing a Pattern if you don’t have grep on your system. Incidentally, the name grep comes from an ancient Unix line editor command g/RE/p, the command to find the regex globally in all lines in the edit buffer and print the lines that match—just what the grep program does to lines in files.

[18] REDemo was inspired by (but does not use any code from) a similar program provided with the now-retired Apache Jakarta Regular Expressions package.

[19] On Unix, the shell or command-line interpreter expands *.txt to all the matching filenames before running the program, but the normal Java interpreter does this for you on systems where the shell isn’t energetic or bright enough to do it.

[20] Or a few related Unicode characters, including the next-line (\u0085), line-separator (\u2028), and paragraph-separator (\u2029) characters.

[21] You might think this would hold some kind of world record for complexity in regex competitions, but I’m sure it’s been outdone many times.

Get Java Cookbook, 3rd Edition now with the O’Reilly learning platform.

O’Reilly members experience books, live events, courses curated by job role, and more from O’Reilly and nearly 200 top publishers.
