Chapter 4. Exploring LINQ to Entities in Greater Depth

In Chapter 3, you wrote the same basic query over and over and over again. I hope you’ll agree that this was a great way to get exposure to the many different ways of writing queries against the Entity Data Model.

There is a lot more to querying an EDM, however. You’ll need to learn about the flexibility you have for expressing complex queries, projecting data, combining and nesting queries, and writing parameterized queries. There are also nuances regarding what type of data is returned based on how you construct your queries. Sometimes you will get objects, as you saw in the examples in Chapter 3, but other times you will get unknown objects (anonymous types). It is also possible for Object Services queries to return rows and columns. You’ll need to know when to expect these varied forms of data to be returned.

Covering all of this exhaustively would require hundreds of pages. Therefore, the goal of these next two chapters on LINQ to Entities and Entity SQL is to teach you the critical features and many of the possibilities, focusing on the most typically needed query features. You will learn how to project specific values (rather than entire objects) in queries, how to query across relationships, how to write nested queries and joins, and how to control when trips are made to the database. Along the way, I will introduce and explain additional new concepts to help you truly understand the workings of the Entity Framework.

This chapter will focus on LINQ to Entities and introducing new concepts. The queries you build here will be demonstrated using Entity SQL in Chapter 5.

Throughout the rest of the book, you will see variations on queries that take advantage of even more techniques as we use queries in real-world examples.

A number of resources provide many specific examples of queries. Here you will learn some of the more common query tasks so that you will know enough to write queries without constantly having to search online for the perfect example of what you are trying to accomplish. It is also useful to check out resources such as the 101 LINQ Examples on MSDN (for VB and for C#), the number of great books dedicated to LINQ, and the Entity Framework Samples, which provide a great variety of query examples with helpful commentary.

Due to some syntax differences between VB and C# when creating LINQ expressions, you will see a number of Visual Basic examples in this chapter along with the C# versions when the difference is significant.

Getting Ready with Some New Lingo

Here is a list of terms used in this chapter (and throughout the book) that may be new to you:


Selecting specific properties or expressions in a query, rather than the entity being queried. For example: from c in context.contacts select c.firstname + c.lastname, c.contactID.

Eager loading

Requesting that related data be returned along with query results from the database. For example: when querying contacts, eager-load their addresses. The contacts and their addresses will be retrieved in a single query.

Deferred loading

Delaying the loading of related data until you specifically request it. For example: when working with query results for a particular contact, you can make a request to retrieve that contact’s addresses from the database. When deferred loading happens automatically (implicitly), it is called lazy loading.


Moving from an entity to its related data. For example: navigate from a contact to its addresses using the contact.Addresses property.

Projections in Queries

So far, the queries you have seen return an entire object, comparable to writing a SELECT SQL query requesting every column in a table. By returning an entire object in your query, you will get all of the benefits associated with the entity classes—the most important of which is the ability to keep track of changes to an entity class for database updates.

Often in SQL, you will select particular columns to return from a table (SELECT Firstname, Lastname FROM Contact) or from a set of joined tables. This is referred to as projection. With LINQ or Entity SQL queries you can shape your results by picking particular properties or expressions rather than entities. You can also select properties from related data.

In the Chapter 3 queries, you returned an entire object but used only the Title, FirstName, and LastName properties. You can rewrite those queries to return only these three properties. As long as you won’t need to modify and update these results, a projection will suffice.

Projections in LINQ to Entities

To see how projections work, you can continue modifying the QueryContacts method that you worked on in Chapter 3. Replace the latest version of the query with the query in Example 4-1. The difference from earlier LINQ queries is that rather than ending with select c to select the entire contact, you are selecting only a few properties.

Example 4-1. Simple LINQ to Entities query with projection in VB and C#

Dim contacts = From c In context.Contacts
               Where c.FirstName= "Robert" _
               Select New With {c.Title, c.LastName, c.FirstName}
var contacts = from c in context.Contacts
               where c.FirstName=="Robert"
               select new { c.Title, c.FirstName, c.LastName };


Why are we back to using Dim and var again? You’ll see the reason shortly in the section titled Implicitly typed local variables.

VB and C# Syntax Differences

You may have noticed the syntax differences between VB and C# projections. This is not particular to LINQ to Entities, but it is common for all implementations of LINQ.

C# requires that you use select new {...} when projecting. Visual Basic is more lenient. The most explicit syntax for VB is Select New With {...} as in Example 4-1, though you could write the Visual Basic query in this simpler format:

From c In context.Contacts _
             Where c.FirstName= "Robert" _
             Select c.Title, c.LastName, c.FirstName


There are plenty of other nuances to LINQ projections in both languages. For example, you can project into predefined types. In addition, C# projections always create immutable (read-only) results, whereas VB allows the creation of immutable and mutable results. You can learn more about projecting with LINQ in the MSDN Library and from the many great resources that focus on LINQ.

LINQ Projections and Special Language Features

A number of language and compiler features that were added to Visual Basic and C# (in the VB 9 and C# 3.0 versions that were released along with Visual Studio 2008 and .NET 3.5) have made it easier for developers to implement LINQ projections. We’ll examine several of these in this section, including anonymous types and implicitly typed local variables.

If you hover your mouse pointer over the contacts variable, when the code is not running, the DataTip will show you what the query returns. It’s an IQueryable of an “anonymous type,” rather than an IQueryable of contact types. The anonymous type is a result of the projection in your query, which returned results that don’t match a defined type. The DataTips and debuggers in Visual Basic and C# often show different information. In this case, the difference is interesting, as you can see in Figures 4-1 and 4-2.

The DataTip in Visual Basic, which shows the new contacts variable to be an IQueryable(Of <anonymous type>)

Figure 4-1. The DataTip in Visual Basic, which shows the new contacts variable to be an IQueryable(Of <anonymous type>)

The DataTip in C#, which shows even more details regarding the anonymous type

Figure 4-2. The DataTip in C#, which shows even more details regarding the anonymous type

Anonymous types

What is this anonymous type that the LINQ to Entities projection is returning?

The anonymous type is a language enhancement that was introduced in Visual Basic 9 and C# 3.0 that allows compilers to work with types that were not previously defined. Anonymous types are generally used for on-the-fly types that won’t be used elsewhere in the application. You cannot even pass them from one method to another. Anonymous types relieve you from having to define a class for every type, even if the type is to be used only briefly. Yet an anonymous type returned by the query is still strongly typed, which means you can easily interact with it in the code following its creation.

The sidebar Wrapping Your Head Around Lambdas includes a link to an article by Anson Horton. The article contains a great introduction to anonymous types. Anonymous types are a powerful feature that you can use throughout .NET, but they have special importance for LINQ queries because of their ability to allow projections that can return anything a developer can dream up.

So, the query in Example 4-1 returned an anonymous type that doesn’t have a name, but has the properties Title, FirstName, and LastName. If you are still modifying the earlier query method, you can see a bit of .NET magic by removing the Console.WriteLine method and retyping it. The anonymous type is strongly typed and recognized by IntelliSense. Pretty cool!

Implicitly typed local variables

Another new compiler trick that you have been taking advantage of in some of the code samples so far is the use of implicitly typed local variables. In C# you use them with a new keyword, var, and in VB you use them with the existing Dim keyword. It is possible to declare variables without identifying their types. They will infer the type based on the value that is being set.

Hasn’t it always seemed redundant to say something like Dim str as String="this is some text" or int MyInt=123? With implicitly typed local variables, Dim str="this is some text" and var MyInt=123 are enough. In the case of replacing int with var the benefit is not very obvious. Had that type been MyCustomType<Myothercustomtype<T>>, suddenly var would look pretty convenient.


This shortcut is not always a good thing, as it removes some of the explicitness of your code. I wrote a blog post on titled “How Visual Studio 2008 made me even lazier” ( There is an interesting discussion in the comments about the pros and cons of implicit typing. Throughout the book, I will attempt to declare types explicitly for the sake of clarity. However, in cases where the type name is quite long, you may find a var in its place.

Where implicitly typed local variables really shine, however, is with LINQ query projections, because there’s no way to say “Dim contacts as a thing with a Title, a FirstName, and a LastName.” Instead, you can write “Dim contacts (and just look at the other side of the equals sign to figure out what this is).” In this context, Dim in VB and var in C# essentially translate to “thing,” or for some readers, “whatever.”

Run the application and you’ll see that, once again, the results are the same as they were previously. You can modify the Console.WriteLine command to include the Title property that is in the newest query.


In Chapter 10, you will learn more about Object Services and all of the functionality it provides to objects returned by queries against the EDM. This will help you better understand the significance of returning anonymous types rather than entire entity objects defined by the EDM.

Implicit and explicit anonymous type creation

You can project into anonymous types in a number of ways. For instance, it is possible to give a name to the returned variable, such as ContactName in Example 4-2.

Example 4-2. Naming a projected anonymous type in LINQ in VB and C#

From c In context.Contacts _
Where c.FirstName = "Robert" _
Select ContactName = New With {c.Title, c.LastName, c.FirstName}
from c in context.Contacts
where c.FirstName == "Robert"
let ContactName = new {c.Title, c.LastName, c.FirstName}
select ContactName

C# does not allow naming in the SELECT statement; it has another operator, LET, that can be used for this purpose.


There are so many ways to do projection and use anonymous types in LINQ queries. Here you are seeing just a small slice of what you can achieve, so be sure to look to the dedicated LINQ resources to expand your understanding.

Naming the anonymous type is more useful if this new type is a property of the projected results. In Example 4-3, a projection is used to project much more than some strings. It creates a new type with another anonymous type as the first property and the addresses of the contact as the second.


I’m projecting the Addresses property here to highlight the projection. You’ll learn more about working with related data later in this chapter.

When you name the anonymous type, the property that results will have the name specified in the query. Notice that the property name is used later in the query for the Order By operator and when working with the results.

Example 4-3. Anonymous types as properties

var contacts =
      from c in context.Contacts
      where c.FirstName == "Robert"
      let foo= new {
                   ContactName = new {c.Title, c.LastName, c.FirstName},
      orderby foo.ContactName.LastName
      select foo;

foreach (var contact in contacts)
  var name = contact.ContactName;
  Console.WriteLine("{0} {1} {2}: # Addresses {3}",
                    name.Title.Trim(), name.FirstName.Trim(),

Figure 4-3 shows the shape of the new range variable, foo. The first property is the ContactName anonymous type.

A named anonymous type with a named anonymous type property

Figure 4-3. A named anonymous type with a named anonymous type property


Unlike the ContactName anonymous type in this query, the Address entities that this query returns will participate in the change tracking and database updates.

Projections with LINQ Query Methods

To project using LINQ’s method-based query syntax, you would use the Select method and then identify the properties you want in its parameter. The method-based query syntax requires the syntax for creating an anonymous type in the lambda (see Example 4-4).

Example 4-4. Projecting using LINQ’s method-based syntax

.Where(c => c.FirstName == "Robert")
.Select(c => new {c.Title, c.LastName, c.FirstName})

Using Navigations in Queries

One of the big benefits that the EDM lends to querying is that the relationships are built into the model and you won’t have to construct joins very often to access related data. Additionally, when using LINQ for the queries, the related data is presented via IntelliSense, which makes it very discoverable.

Using the model, let’s take a look at some more queries, this time digging into associations.

The model has only one association, that which lies between Contact and Address. The association provides two navigations—one from Contact to all of its related addresses and one from Address to its related contact.

You can easily do projection, drilling into related entities, although drilling into a collection is different from drilling into a reference entity. For example, you can’t request Contact.Addresses.Street in a query. Contact to Addresses is a one-to-many relationship and Addresses is a collection of Address entities, not a single entity. Street is not a property of the Addresses EntityCollection. However, you could select Address.Contact.LastName, because you would be navigating to a single entity. There is only one contact per address; therefore, there is no question regarding from which entity the query should retrieve the LastName.

Navigating to an EntityReference

Recall that navigating to the “one” end of a one-to-one or many-to-one relationship is referred to as a navigation reference. The entity you are pointing to is referred to as an EntityReference, sometimes called an EntityRef.


Chapter 19 will drill further into EntityReferences and EntityCollections, and how they are surfaced as navigation properties.

The LINQ query in Example 4-5 returns an anonymous type containing an address and its related contact.

Example 4-5. Projecting into an EntityRef with LINQ to Entities

var addresses = from a in context.Addresses
                where a.CountryRegion == "UK"
                select new { a, a.Contact };

Figure 4-4 displays the anonymous type that results in the debugger, where you can see that one property is the address record and the other is the contact.

The query results, which contain a new type with the address and its contact

Figure 4-4. The query results, which contain a new type with the address and its contact

When working with the results, you’ll have to drill into the new type’s properties (the Address and the Contact) and from there you’ll have to drill into their properties, as shown in Example 4-6.

Example 4-6. Accessing the properties of an anonymous type

foreach (var address in addresses)
  Console.WriteLine("{0} {1} {2}",
                   address.Contact.LastName, address.a.Street1,


The first property is named a because it is using the variable name given in the query. If you want to be sure the property is called Address you can use that instead of the simpler a, or use LINQ syntax to rename the property:

Select New With {.Address = a, a.Contact}
select new {Address= a, a.Contact };

Then you can work with address.Address in the data which results.

Although this may suit many scenarios in your applications, you may prefer to project individual properties from the reference navigation. Example 4-7 shows such a query using LINQ to Entities. This projection returns a new type with three properties. The first is an Address entity; the second and third are strings. Again, the property names are based on the query defaults—a, FirstName, and LastName.

Example 4-7. Combining properties from related entities

var addresses = from a in context.Addresses
                where a.CountryRegion == "UK"
                select new { a, a.Contact.FirstName,
                             a.Contact.LastName };

foreach (var address in addresses)
  Console.WriteLine("{0} {1} {2} {3}",
                    address.FirstName, address.LastName,
                    address.a.Street1, address.a.City);

Filtering and Sorting with an EntityReference

You can filter and sort based on a property of an EntityReference whether or not you are selecting the related data.

For example, you can select all addresses for contacts with a particular last name. The LINQ to Entities query in Example 4-8 sorts by Contact.LastName and filters on the Contact.AddDate field even though AddDate is not part of the results.

Example 4-8. Filtering and sorting on reference properties

from a in context.Addresses
where a.Contact.AddDate > new System.DateTime(2009, 1, 1)
orderby a.Contact.LastName
select new {a, a.Contact.LastName};

Navigating to Entity Collections

Querying with related data is straightforward when the related data is a single entity, but what about when the navigation property is an EntityCollection such as Contact.Addresses?

Let’s start with a simple scenario that you have seen a few times already in this chapter: returning a contact and its collection of addresses. To highlight the difference between the original properties and the results, the EntityCollection in the new type is given a random name, as shown in Example 4-9.

Example 4-9. Projecting an EntityCollection with LINQ

var contacts =  from c in context.Contacts
                select new {c, Foos = c.Addresses};

This query creates a new anonymous type with two properties. The first is the Contact and the second is Foos, which is the EntityCollection of Addresses related to that Contact.

You can enumerate through the results, and then, for each result, enumerate through the collection of the Foos property, as shown in Example 4-10.

Example 4-10. Enumerating over shaped data that includes an EntityCollection

foreach (var contact in contacts)
  Console.WriteLine("{0}: Address Count {1} ",
                    contact.c.LastName.Trim(), contact.Foos.Count);
  foreach (var foo in contact.Foos)
    Console.WriteLine("   City= {0}", foo.City);

Projecting Properties from EntityCollection Entities

If you wanted to select particular properties such as Street and City from each Address of each Contact, the method you should use to build the query depends on what shape you want the results to be.

Shaped results

You could shape the data similar to the previous example, but instead of a set of complete address entities as the Foos property, you can project some of the address properties. This would result in a set of anonymous types, named StreetsCities instead of Foos, in the second property.

You can achieve this with a nested query, a feature we’ll look at more closely later in the chapter. For now, you can see in the query in Example 4-11 that the third property, StreetsCities, contains the results of querying the Contact’s Addresses.

Example 4-11. Projecting values from an EntityCollection

from c in context.Contacts
select new {c.FirstName, c.LastName,
            StreetsCities = from a in c.Addresses
                            select new { a.Street1, a.City }

The anonymous type that is returned has the properties FirstName and LastName, along with a collection of anonymous types with Street1 and City properties. The debugger screenshot in Figure 4-5 displays the new type.

The newly shaped anonymous type

Figure 4-5. The newly shaped anonymous type

Flattened results

Another way to project into the addresses is to merely turn the query around. That is, query the addresses and their contact data to flatten the results, as shown in Example 4-12, so that the data is no longer shaped.

Example 4-12. Flattening the related data

var contacts =
from a in context.Addresses
orderby a.Contact.LastName
select new {a.Contact.LastName, a.Contact.FirstName, a.Street1, a.City};

This will result in a single type with four properties, but contacts with multiple addresses will appear multiple times, as you can see in this section of the results. For instance, Katherine Harding and Keith Harris each have two results:

Hanson, John: 825 W 500 S, Bountiful
Harding, Katherine: 52560 Free Street, Toronto
Harding, Katherine: 25   Flatiron Blvd., Vancouver
Harrington, Lucy: 482505   Warm Springs Blvd., Fremont
Harris, Keith: 3207 S Grady Way, Renton
Harris, Keith: 7943   Walnut Ave., Renton
Harui, Roger: 9927 N.   Main St., Tooele
Hass, Ann: Medford Outlet  Center, Medford

Filtering and Sorting with EntityCollections

Although you can easily use related data in projections or for filtering, sorting, and other operations, it is important to keep in mind that when the related data is in a collection, you need to leverage operations that can be performed on a set of data. For example, if you want to find contacts with addresses in the United Kingdom (represented as UK in the database), you can use the ANY method in LINQ to Entities (see Example 4-13) or the EXISTS operator in Entity SQL (which you’ll see in the next chapter) to search the contact’s addresses. The LINQ query uses a predicate to provide the condition for ANY.

Example 4-13. Filter condition provided by an EntityCollection with LINQ

from c in context.Contacts
where c.Addresses.Any(a => a.CountryRegion == "UK")
select c;

Aggregates with EntityCollections

Aggregates perform calculations on a series of data. Aggregate methods include Count, Sum, Average, Min, and Max. You may not want the entire collection of addresses, but rather some aggregated information about that collection.

Aggregates in LINQ to Entities

Aggregating data with LINQ is easyusing one of the aggregate methods such as Count; simply append the method to the collection name. The Count method will return the count of the items in the collection (see Example 4-14).

Example 4-14. Using the Count aggregate method in LINQ to Entities

from c in context.Contacts select new {c.LastName, c.Addresses.Count};

Other types of aggregates, such as Max, require a specific value to aggregate. You can supply that value using a lambda expression, as shown in Example 4-15.

Example 4-15. Using an aggregate method with a lambda in LINQ

from c in context.Contacts
select new { c.LastName, MaxPC = c.Addresses.Max(a => a.PostalCode)};

It’s important to name the property returned by the aggregate function, because LINQ is unable to derive one based on the method. If you forget to do this, both VB and C# will give a compiler error explaining the problem.


Visual Basic has an Aggregate operator for LINQ that you can use in place of FROM in your LINQ queries. Check the MSDN Library topic “Aggregate Clause (Visual Basic)” for more information.

Aggregates in LINQ Methods

The LINQ aggregates are methods, not query operators. Therefore, they work very naturally with the LINQ query methods. Example 4-16 uses the Max aggregate as one of two projected values to be returned.

Example 4-16. A LINQ method syntax query using an aggregate

  .Select((c) => new { c.LastName,
              MaxCode = c.Addresses.Max(a => a.PostalCode) });

This query does two interesting things with the lambdas. First it uses a lambda expression to specify what values should be projected: LastName and MaxCode. Once the variable, c, has been declared, the function projects an anonymous type consisting of LastName as the first property and MaxCode as the second. MaxCode is defined by using the Max aggregate on the Addresses collection of the contact.

Joins and Nested Queries

Although associations in the EDM minimize the need for joins in queries, sometimes a relationship may exist but there is no association to represent the relationship. In these and other cases, you can use nested queries or joins to bring the data together.

LINQ to Entities provides a JOIN operator as well as GROUPJOIN. Entity SQL provides a variety of options in the JOIN FROM clause, including inner joins, as well as left, right, and full outer joins. It also enables joining multiple collections separated by commas.


The vOfficeAddresses entity in the current model has all of the contact properties except for the contact’s Title. Because there is no association between vOfficeAddresses and Contact, you will need to use JOIN to combine the vOfficeAddresses entity properties with the Title property.


You could, of course, add the association to the model in this case, but then there would be no lesson here, would there?

Example 4-17 shows the syntax of a LINQ JOIN.

Example 4-17. JOIN syntax for LINQ

FROM [variableA] IN collectionA
JOIN [variableB] IN collection
ON variableA.commonproperty EQUALS variableB.commonProperty
SELECT .....

Example 4-18 shows how to combine data from Contact entities and vOfficeAddresses entities using the JOIN.

Example 4-18. A LINQ to Entities query using a JOIN

from c in context.Contacts
join oa in context.vOfficeAddresses on c.ContactID equals oa.ContactID
select new { oa.FirstName, oa.LastName, c.Title, oa.Street1, oa.City,
             oa.StateProvince };

This provides an inner join where only entities with matching ContactIDs are returned. Any contacts with no match in the vOfficeAddresses will not be returned. vOfficeAddresses with no match in Contacts will not be returned either.

Nested Queries

Both LINQ and Entity SQL provide the ability to nest queries, and you have already seen some examples of this. When you write a query, anywhere a value is expected you can use another query in its place, as long as that query returns an acceptable type. You can use a nested query in place of an expression or a collection, as you will see in the following examples.

The goal of the previous JOIN queries was to return properties from a Contact entity combined with properties from the vOfficeAddresses entities where the ContactID matches.

Using a nested LINQ query as a projection

Example 4-19 shows how to express the previous query in LINQ using a nested query instead of a JOIN. The query uses a nested query (highlighted) combined with the FirstOrDefault method in place of a projected value to return results from vOfficeAddresses.

Example 4-19. Nested query in place of a SELECT expression in LINQ

from oa in context.vOfficeAddresses
select new { oa.FirstName,  oa.LastName,
             Title = (from c in context.Contacts
                      where c.ContactID == oa.ContactID
                      select c.Title).FirstOrDefault(),
             oa.Street1, oa.City, oa.StateProvince

There are a few notable twists to this query. The first should be familiar: an anonymous type is not able to automatically name the return from the nested query. Therefore, it is given the name “Title”. The second twist is that the subquery returns an IQueryable of String, not just a string, which is why the FirstOrDefault method is appended to the query.

Using a nested LINQ query as the collection to be queried

You can also use the nested query in place of the collection being queried. The nested query merely returns another collection to be queried.

Let’s start with a basic example. Rather than querying all vOfficeAddresses, you could create a subquery that returns only vOfficeAddresses in Ontario and then query against that. Example 4-20 is simplistic and could easily be expressed without the nested query. The technique can be useful when you are attempting to express queries that are much more complex.

Example 4-20. Nested query in place of a target collection in LINQ

var contacts = from add in
                 (from oa in context.vOfficeAddresses
                  where oa.StateProvince == "Ontario" select oa)
               select ...

You can benefit from using nested queries to help with complicated queries by separating the nested query from the main query.

On its own, this particular example doesn’t seem very useful, but imagine being able to use subqueries to redefine the universe of vOfficeAddresses from which to query, and then passing that into different methods which will perform additional queries on that subset.

Example 4-21 ties a subquery to a variable and then uses that variable in another query. The second query is complex enough, using another nested query to join vOfficeAddresses back to Contact. Breaking up the query makes the code much more readable. When the query is executed, the Entity Framework will create a single query from the combined expressions.


Don’t forget the importance of knowing what is going on at the database level by using some type of profiler, as suggested in Chapter 3.

Example 4-21. Breaking a nested query out of the main query in LINQ

var universe = from oa in context.vOfficeAddresses
               where oa.StateProvince == "Ontario"
               select oa;

var query = from oa in universe
               select new
                 contact = (from c in context.Contacts
                            where c.ContactID == oa.ContactID
                            select c)
var AddressesWithContacts = query.ToList();


You can’t separate out a nested query that’s inside a projection, as in Example 4-21, because its filter condition is dependent on the main query.


An Order operator in a subquery will be ignored. The main query controls ordering.


Both LINQ and Entity SQL provide operations for grouping data. You can use grouping in connection with aggregates or to shape data.

LINQ to Entities has a Group operator (literally Group By in Visual Basic and Group in C#) and a GroupBy method (with eight overloads). Entity SQL provides a GROUP BY operator and a GroupBy query builder method.

The results of the grouping can use automatic naming, and in other cases can be explicitly named. In addition, an INTO GROUP clause is required in Visual Basic. C# has an optional INTO clause.

The constructs for VB and C# are quite different and it’s easiest to explain them with examples. Example 4-22 shows the simplest form of grouping in LINQ for both Visual Basic and C#.

Example 4-22. Simple grouping in LINQ to Entities in VB and C#

From c In context.Contacts Group By c.Title Into Group
from c in context.Contacts group c by c.Title into mygroup select mygroup

The result of this query is an IQueryable of an Entity Framework class called Grouping; more specifically, System.Data.Objects.ELinq.InitializerMetadata.Grouping<K,T>. In our example, it’s a Grouping<string,Contact>. This is something like a key/value pair where the key is K (the string in our example) and the value is an IEnumerable of T (e.g., the group of Contact types).

The results, therefore, are a set of these key/value pairs. If we select one of the groupings, as you can see in Figure 4-6, VB automatically names the property containing the title as “Title”.

The VB result, which contains a Title property and a Group property that contains three contacts

Figure 4-6. The VB result, which contains a Title property and a Group property that contains three contacts

By default, C# uses the word Key as the name for the key of the grouping and doesn’t name the property that contains the grouped records, as you can see in Figure 4-7.

Default C# grouping

Figure 4-7. Default C# grouping

VB allows you to specify the property name rather than use the default. In Visual Basic, to change the Title property of the preceding query to MyTitle, you would use the syntax Group By MyTitle=c.Title.

In VB, the Group property is available to access the group. You can rename this as well. For example, Into MyGroup = Group renames the property to MyGroup.

Naming Properties When Grouping

The optional INTO clause in C# allows you to specify a group name, but this is not exposed as a property. You specify the name with INTO so that you can perform further functions on the group. Note that in C#, using the INTO clause requires that you also use the SELECT clause. The Key property is then accessible as a property of the group.

With the group specified, it is now possible to explicitly name the properties in C#. LINQ queries in Visual Basic will imply a SELECT statement if it is not used. In this case, the query will still return Title and MyGroup by default without specifying SELECT. Of course, you can shape the data further by specifying your own output with an explicit SELECT operator.

Example 4-23 demonstrates these changes to the previous queries.

Example 4-23. LINQ Group By with explicitly named groups and targets in VB and C#

From c In context.Contacts _
Group By c.Title Into MyGroup = Group
from c in context.Contacts
group c by c.Title into MyGroup
orderby MyGroup.Key
select new {MyTitle = MyGroup.Key, MyGroup};

Chaining Aggregates

Visual Basic provides a simple way to use aggregates in grouping queries, by specifying one or more aggregates in the INTO clause separated by commas. In Example 4-24, your result will contain the properties Max and Count.

Example 4-24. Chained aggregates in VB LINQ

From c In context.Contacts _
Group By c.Title Into MyGroup = Group, _
Max(c.AddDate), Count()

In C#, you need to explicitly project these properties in the Select clause using methods and predicates, as shown in Example 4-25.

Example 4-25. Combining aggregates in C# LINQ

from c in context.Contacts
group c by c.Title into MyGroup
orderby MyGroup.Key
select new {MyTitle = MyGroup.Key, MyGroup,
            Max = MyGroup.Max(c => c.AddDate),
            Count = MyGroup.Count()}

Filtering on Group Conditions

There is so much more that you can do with grouping in LINQ. For now, we’ll take a look at one more variation: filtering on the grouping condition.

The Title fields in the sample data contain Mr., Mrs., Ms., Sr., and a few other titles. Also, some contacts have no title. Perhaps you would like to group on title, but exclude empty titles. To filter what is being grouped, such as “only group contacts with something in the Title field,” you can apply the filter to the control variable, Title, to make sure it contains a value.

You may, however, want to filter on a property of the Group. With LINQ you can continue to use the WHERE operator, as shown in Example 4-26.

Example 4-26. Filtering on a Group property with LINQ

From c In context.Contacts _
Group By c.Title Into MyGroup = Group, Count() _
Where (MyGroup.Count() > 150)
from c in context.Contacts
group c by c.Title into MyGroup
where MyGroup.Count() > 150
select new { MyTitle = MyGroup.Key,
             Count = MyGroup.Count()};

In LINQ, you will also need to be aware of variables going out of scope, as in the Visual Basic query shown in Example 4-27, which won’t compile. The a in Group by a.CountryRegion is out of scope because by this point in the query, you are working with the anonymous type returned by the Select statement. And the Select does need to go before the Group By.

Example 4-27. An out-of-scope variable preventing this query from compiling

From a In context.Addresses _
Select a.Contact.FirstName, a.Contact.LastName, a.CountryRegion _
Group By a.CountryRegion Into MyGroup = Group, Count() _
Where (MyGroup.Count() > 150)

You can avoid this problem by naming the anonymous type, and then grouping by a field within the name, as shown in Example 4-28.

Example 4-28. Naming variables to keep them from going out of scope

From a In context.Addresses _
Select c = New With {a.Contact.FirstName,
                             a.Contact.LastName, _
                             a.CountryRegion} _
Group By c.CountryRegion Into MyGroup = Group
from a in context.Addresses
let c= new {a.Contact.FirstName, a.Contact.LastName,
            a.CountryRegion} group c by c.CountryRegion
            into MyGroup where (MyGroup.Count() > 150)
            select MyGroup;

Both the Visual Studio documentation and the ADO.NET Entity Framework documentation and samples can provide you with an astounding array of data shaping that you can perform with Group By/groupby in LINQ, and even then there are still many more.


See Finding More Query Samples for links to these resources.

Like everything else this chapter has covered so far, we have only skimmed the surface of GROUP BY in Entity Framework queries. You will see more uses throughout this book and can find more details (and plenty of rules) in the documentation. The rest of this chapter will explain some important concepts that have been exposed by the queries you’ve seen so far.

Shaping Data Returned by Queries

Whether you write a query that returns entities, anonymous types, DbDataRecords, or DbDataReaders, you can return shaped data. You’ve seen this in several of the previous queries, with a variety of shaped results. How you use this data depends on how the data is shaped. Let’s take a further look at the results of some of the earlier queries.

The LINQ and Object Services queries that returned entities defined in the model are not shaped. They are purely a collection of individual entities.

For instance, Example 4-13 returned an IQueryable of Contact objects. Example 4-9, however, returned an anonymous type with two properties. The first property was a Contact entity and the second was a collection of Address entities related to that Contact. The code in Example 4-10 enumerated over that data, albeit in a somewhat boring way, to demonstrate what the data looked like. It showed the contacts and the addresses but did not truly demonstrate the relationship between the two.

Example 4-29 executes the same query and then enumerates through the anonymous types that result. This time, however, the code accesses the Addresses as a navigation property of the Contact.

LazyLoadingEnabled is set to false to ensure that the Count method does not impact the results.

Example 4-29. LINQ query creating shaped results

var addressGraphs = from a in context.Addresses
                    where a.CountryRegion == "Canada"
                    select new { a, a.Contact };

foreach (var ag in addressGraphs)
  Console.WriteLine("LastName: {0} # Addresses: {1} ",
    ag.Contact.LastName.Trim(), ag.Contact.Addresses.Count());

  foreach (Address address in ag.Contact.Addresses)
    Console.WriteLine(".....{0}", address.City);



There’s a simpler way to express this particular query with the Include method, which you will see next. But what differentiates this from Include is that with it you can take the projection in Example 4-29 a step further in a direction that you won’t be able to do with Include. I’ll discuss this after we look at the results of this example.

Let’s turn the query around a bit to see how this can work. Imagine you are querying contacts and want to also return their addresses.

The WriteLine method doesn’t access the a property of the anonymous type, but instead navigates to the addresses through the Contact property of the anonymous type.

As the Contact and Address entities are materialized, the Entity Framework recognizes that they are related to each other and wires them up so that you can navigate between them. The Address objects have a Contact object in their Contact property and the Contact objects have Address objects in their Addresses property. This is a very high-level explanation of an important function of the Entity Framework’s Object Services API, which you will learn plenty about throughout the book.

There is an interesting thing to be aware of with respect to how the Entity Framework connects the related entities in the scenario laid out in Example 4-29. If you look at the following sample of the output, you can see that two addresses belong to the contact “Harding.” One is in Toronto and the other is in Vancouver. But the first instance says that Harding has only one address. Not until the code has reached the second address is the contact aware that two addresses exist in its Addresses navigation collection.

LastName: Garza # Addresses: 1

LastName: Harding # Addresses: 1

LastName: Harding # Addresses: 2

LastName: Caprio # Addresses: 1

LastName: Blackwell # Addresses: 1

LastName: Hamilton # Addresses: 1
....Chalk Riber

The second address isn’t recognized initially because it hasn’t been materialized as an object yet. As the code enumerates through the query results for the first time, the objects are created from the query results as each contact or address is reached. Once the second address is encountered and turned into an object, its relationship to the contact is identified.


I had you disable lazy loading in order to see this because when you requested Addresses.Count, lazy loading would have kicked in and gone to the database to retrieve the contact’s complete Addresses collection. For the sake of the demo, I did not want this behavior. You’ll learn more about lazy loading further on in this chapter, and later in the book as well.

We will explore the object life cycle more deeply in a later chapter, but this should give you some idea for now about what’s going on in this example.

Limiting Which Related Data Is Returned

At the end of the previous example, I mentioned that projections will allow something that the upcoming Include method won’t allow. That is the ability to filter which related data is returned.

If you were querying for contacts with their addresses, a projection would look like this:

var contactGraphs = from c in context.Contacts
                    select new { c, c.Addresses };

You can modify the query to load all of the contacts, but only a subset of their addresses, as in Example 4-30.

Example 4-30. Filtering related data in a query using projections

var contactGraphs = from c in context.Contacts
                    select new { c, MyAddresses = c.Addresses.Where(a=>a.CountryRegion="UK")};

I’ll refer back to this example as we look at other means of loading related data.

Loading Related Data

So far, all of the queries that involved returning related data have explicitly asked for that data in the query itself. The Entity Framework will only return data that you explicitly ask for. If your query asks only for contacts, the Entity Framework will not make an assumption that just because contacts have addresses, it should return the addresses anytime you query for contacts. Consider a typical model for sales information. A contact is related to a customer; a customer has sales orders; each sales order has line items; each line item relates to a product; each product comes from a vendor and is also related to a category. Can you imagine if you queried for contacts, and without expecting it, the entire contents of the database were returned—because it was all related?

It is possible to get related data after the fact. For example, if you queried for a selection of contacts, as you work with those contacts in code you can request the contacts’ addresses without performing another complete query.


For developers coming from the first version of Entity Framework, there is a big change to be aware of here. The implicit, automatic loading of related data, controlled by the ObjectContext.ContextOptions.LazyLoadingEnabled property, is a new option in the Entity Framework. It is enabled (i.e., set to true) by default, for newly created models. The property will be false on existing models pulled into .NET 4 to prevent breaking changes in your existing code.

This is referred to as deferred loading or implicit deferred loading, and is most commonly known as lazy loading.

As of .NET 4, Entity Framework performs lazy loading by default.

The LINQ to Entities query in Example 4-31 returns an ObjectSet of Contact entities. As the code enumerates through the results, it also asks for information about the related Addresses. But the Addresses were not returned with the original query.

Example 4-31. Implicitly loading related data after the fact

var contacts= from c in context.Contacts select c;
foreach (var contact in contacts)
  Console.WriteLine("{0} #Addresses: {1}",

Unlike the filtered projection in Example 4-30, lazy loading has no means of filtering the data being loaded.

However, each time the code hits a request for the address count of the current contact, a new query will be executed on the server to retrieve the addresses for the current contact. You should understand that this means that if there were 10 contacts in the original result, there will be 10 additional trips to the database as you iterate through the 10 contacts.

Controlling Lazy Loading

Lazy loading is surely convenient, but if you are not paying attention, you could be abusing your server resources by unknowingly or even unnecessarily causing repeated trips to the database. You can disable (and reenable) lazy loading as needed in code or modify the default behavior for the context. There are other ways to load related data when you need it even if you are not depending on lazy loading.

Disabling and enabling lazy loading programmatically

Lazy loading can be controlled through the ObjectContext’s ContextOptions.LazyLoadingEnabled property:

var context = new SampleEntities();
context.ContextOptions.LazyLoadingEnabled = false;

Once it is disabled, you can still explicitly load related data on demand if needed, or even load the data along with the initial query. These two methods are covered in the next few pages.

Changing the default behavior for lazy loading

In the default generated classes, the constructors for the ObjectContext (e.g., SampleEntities) set LazyLoadingEnabled based on an annotation in the EDMX. The XML annotation was pointed out in the CSDL EntityContainer section of Chapter 2.

Models that are created in Visual Studio 2010 have this annotation with the value set to true. Models that were created in Visual Studio 2008 SP1 do not have the annotation, and therefore, if you are using an older model, by default, lazy loading will not be enabled.

The Lazy Loading Enabled setting is exposed in the model’s Properties window in the Designer, in the Code Generation section, where you can change the default behavior for a particular model.

Explicitly Loading Entity Collections and Entity References

Let’s return to the query in Example 4-31:

var contacts= from c in context.Contacts select c;

When lazy loading is disabled, because the query does not explicitly request the addresses, the Addresses.Count for every single contact will be zero.

But you can explicitly tell the Entity Framework to get the addresses for the current contact, as shown in the Example 4-32.

Example 4-32. Explicitly loading related data with the Load method

foreach (var contact in contacts)

When Load is called, Object Services will execute a query to retrieve all of the addresses for that contact. In the preceding example, after Load is called, the value of Count will be correct and all of the Address entities for that contact will be available.

Using Load is another case where you cannot filter the related data being loaded as you can with the projection in Example 4-30.

In .NET 4, a new method was introduced to load from the context, not from the navigation property. The method is ObjectContext.LoadProperty and it was created as part of the support for classes that do not inherit from EntityObject. You’ll learn about LoadProperty in Chapter 11.

Loading the EntityReference

You can also perform deferred loading for EntityReference navigation properties—for example, Address.Contact. However, rather than load from the Contact property, you must load from the additional property that was created by the code generation: ContactReference. The Entity Framework sees Address.Contact as merely a Contact entity, and the Contact class does not have the Load method. It is the ContactReference property that has the knowledge of how to load the related information. Each EntityReference navigation property will have a related property with the word Reference appended to its name.

Example 4-33 shows how to load Contact data for particular addresses after the addresses have already been queried.

Example 4-33. Loading the Contact using ContactReference.Load

var addresses = from a in context.Addresses select a ;
foreach (var address in addresses)
  if (address.CountryRegion != null)
    if (address.CountryRegion.Trim() == "UK")

Performance considerations with deferred loading

There is a big performance consideration here. Whether you are lazy-loading or explicitly loading the related data for each contact, the code is forcing an extra round trip to the database, something many developers won’t realize unless they are profiling the database activity. This can be extremely inefficient and might also get you into big trouble with the IT pros in your company. With lazy loading disabled, you can have some control over when the extra trip is made.

Load is a great choice in cases where you want to inspect the contacts and then load addresses for only particular contacts. Perhaps you want to list all contacts, but for contacts that were added after a particular date you need to see how many addresses are in the database. The code in Example 4-34 demonstrates this scenario, where you may determine it is more efficient to make a small number of database trips rather than preloading addresses for every contact.

Example 4-34. Loading addresses for some of the contacts

foreach (Contact contact in contacts)
  if (contact.AddDate > System.Convert.ToDateTime("1/1/2008"))

With lazy loading enabled, this kind of granular control is a bit more difficult to achieve.

The benefit of having lazy loading enabled is that you won’t have to worry about reporting that there are no addresses for a contact when in fact there are a number of them in the database because you forgot to, or didn’t know that you needed to, explicitly load those related addresses.

Using the Include Method to Eager-Load

In cases where you know you will need all of the addresses up front, it may be more efficient to retrieve them as part of the original query. Although you have seen how to do this with projection by including the addresses in the SELECT clause, the Include method is another way to achieve this and may be preferable for a variety of reasons. The most notable reason is that the resultant objects will be your entities, rather than anonymous types with entities as their properties. However, Include does not allow you to filter the related data as you can with a projection.

Include is a query builder method and you can apply it to an ObjectQuery or ObjectSet (which, as you may recall, derives from ObjectQuery). Because context.Contacts is an ObjectSet, you can use Include even within a LINQ query, as shown in Example 4-35.

Example 4-35. The Include method in a LINQ to Entities query

from c in context.Contacts.Include("Addresses")
where c.LastName.StartsWith("J")
select c

The argument for Include is a string that is the name (or names) of the navigation properties to bring back along with the contacts. This is referred to as eager loading or eager fetching.

You can use Include only when returning an ObjectQuery or ObjectSet of a single entity type. You cannot use it with projections, and if you do project, Include will be ignored.

In the sample model, there is only one navigation property for contact, which is Addresses. Imagine a sales model with a number of entities and a variety of navigations. You could query customers and eager-load the orders and all of the orders’ details by querying Customers.Include("Orders.OrderDetails"). The string is called a query path because it defines the path that the query should navigate through the model. This will bring in both the Orders and OrderDetails. Additionally, you could eager-load the orders and the customers’ addresses by chaining the Include methods like this:


How is the data shaped with Include?

Data shaping is one of the interesting benefits of Include. The previous Contacts.Include("Addresses") query returns a set of Contact entities. This does not have the same effect as projection, which would have to return DbDataRecords.

Figure 4-8 shows the query results in the debugger’s QuickWatch window. You can see that the results are strictly a set of Contact entities. Where are the addresses?

The result of the Include with no projections, which returns only the primary entity of the query

Figure 4-8. The result of the Include with no projections, which returns only the primary entity of the query

Figure 4-9 drills into one of the contacts, and you can see that both of this contact’s addresses are there. The Include brings in the related data, and unlike the issue you saw in the results of Example 4-29 (not all addresses were being attached to Ms. Harding from Toronto until the addresses had been enumerated), all of these addresses are present as soon as you get to the contact.

The result of the Include with projections, with lazy loading disabled, which returns the contact’s related Addresses in the query

Figure 4-9. The result of the Include with projections, with lazy loading disabled, which returns the contact’s related Addresses in the query


Lazy loading will still be active when you are inspecting data in debug windows such as the QuickWatch window in Figure 4-9. I disabled lazy loading for the context prior to opening the QuickWatch window. You can also watch a database profiler to ensure that the Addresses count you are looking at is truly a result of eager loading and is not being provided by way of lazy loading and an extra hit to the database.

Accessing properties from an Include in the query

You can use the properties of the Include entities in many of the same ways you can use properties of any related data when querying.

Example 4-36 uses the CountryRegion field of Address to limit which contacts are retrieved. But be sure you are clear on the results. This will return contacts that happen to have any of their addresses in the United Kingdom. If a contact has multiple addresses and only one of them is in the United Kingdom, you will still get all of those addresses.

Example 4-36. Limiting which contacts are retrieved

from c in context.Contacts.Include("Addresses")
where c.Addresses.Any((a) => a.CountryRegion == "UK")
select c


Although you can use the properties of the included data in your query, you cannot filter or sort the included data. There’s no way to say “when you return the addresses along with the contacts, please sort the addresses by city.” Additionally, as mentioned before, you can’t filter the included data either.

Pros and Cons of Load and Include

You have some things to consider when choosing between the Load and Include methods. Although the Load method may require additional round trips to the server, the Include method may result in a large amount of data being streamed back to the client application and then processed as the data is materialized into objects. This would be especially problematic if you are doing all of this work to retrieve related data that may never be used. As is true with many choices in programming, this is a balancing act that you need to work out based on your particular scenario.

The documentation also warns that using query paths with Include could result in very complex queries at the data store because of the possible need to use numerous joins. As the model becomes more complex, the potential for trouble increases.

You could certainly balance the pros and cons by combining the two methods. For example, you can load the customers and orders with Include and then pull in the order details on an as-needed basis with Load.

The correct choice, or combination, will most likely change on a case-by-case basis.

Retrieving a Single Entity

All of the queries so far have returned sets of data. What if you wanted to retrieve a single entity or a single result? The queries return IQueryables or ObjectQuerys and you need to dig into those to get at the actual data, which might be entities, anonymous types, or DbDataRecords.

This is reasonable if you are returning multiple items, but what about cases where you query for one particular item—for example, the contact whose ContactID is 63—and you don’t want to have an IQueryable returned, but just the item?

LINQ to Entities has a pair of methods, First and FirstOrDefault, which will return the first item in the result set. Additionally, Single and SingleOrDefault are useful when you are expecting only one item in the result set—for example, if you are querying for a single contact. These methods are not specific to LINQ to Entities, but come from LINQ and may be familiar to you already.

Example 4-37 shows two techniques for using these methods. In the first technique, a query is defined and then the Single method is called. This will cause the query to be executed and the contact entity to be returned. The second technique appends the Single method directly to the query. Even though Single is a LINQ method, you can combine it with the query operator syntax by wrapping the query in parentheses. In this case, the query is executed immediately and the contact is returned.

Example 4-37. Querying with the Single method

IQueryable<Contact> contacts = from c in context.Contacts
                               where c.ContactID == 1
                               select c;
Contact contact = contacts.Single();
Contact singleContact = (from c in context.Contacts
                         where c.ContactID == 2
                         select c).Single();

There’s a potential problem here. If there are no items, First and Single will throw an InvalidOperationException with the message “Sequence contains no elements.” FirstOrDefault and SingleOrDefault protect you from the exception by returning the default, which is generally a null (Nothing in VB). Additionally, if you use Single or SingleOrDefault but the result set contains more than one item, an exception will be thrown. In that case, you should be using First or FirstOrDefault.

In Example 4-38, SingleOrDefault is used to avoid an exception being thrown. Contact in this case will be Nothing/null after the query is executed.

Example 4-38. Using SingleOrDefault to avoid an exception

var contact = (from c in context.Contacts
               where c.ContactID == 7654321
               select c).SingleOrDefault();

Another way to use these methods is to pass the predicate directly to them, rather than using a where operator.

For example:

var contact = context.Contacts.Single(c => c.ContactID == 1);

Retrieving a Single Entity with GetObjectByKey

The ObjectContext.GetObjectByKey method and its counterpart, TryGetObjectByKey, provide a way to query for an object without having to construct and execute a query. However, this has a notable twist. The runtime will first look in the existing instantiated objects to see whether the object has already been retrieved. If it is found, this is what will be returned. If not, the query to the data store will be executed automatically and the object will be returned.

GetObjectByKey takes an EntityKey type that defines what object to retrieve based on its EntitySet, its key property name, and the value of that property. For example, EntityKey("SampleEntities.Contacts","ContactID",5) defines an object in the Contacts EntitySet with a ContactID value of 5. Once the EntityKey has been created, GetObjectByKey(myEntityKey) will return the object either from memory or from the database.

TryGetObjectByKey uses the .NET Try pattern to avoid returning an exception if the object is not found in memory or in the database.

You will see both of these used many times in later chapters, and you will learn all about the EntityKey class in Chapter 10.


There is also a method for retrieving an entity by only looking in memory and not checking the database, called GetObjectStateEntry. You’ll learn about this method in Chapter 10.

Finding More Query Samples

This chapter is filled with many queries, but there are so many possibilities for querying with LINQ or Entity SQL that you will certainly benefit from checking these other great resources:

MSDN’s 101 C# LINQ Samples

MSDN’s 101 Visual Basic LINQ Samples

MSDN’s Entity Framework Query Samples

There are also a number of excellent books that are focused on LINQ or that contain LINQ content. Some that I recommend are LINQ Pocket Reference by Joseph Albahari and Ben Albahari (O’Reilly), LINQ in Action by Fabrice Marguerie et al. (Manning Press), and Essential LINQ by Charlie Calvert and Dinesh Kulkarni (Addison-Wesley).


In this chapter, you have learned a variety of ways to use LINQ to Entities to express more complicated queries. You have used projections, queried across navigations, and learned how to group. You have also learned about various ways to load related data, whether through returning shaped results with the Include method, retrieving related data after the fact with lazy loading or explicitly calling a Load method. With LINQ to Entities, Entity SQL, Object Services, and EntityClient, the Entity Framework provides myriad possibilities for querying data and shaping results. In the next chapter you will see how many of the queries written in this chapter can be written with Entity SQL.

Although it would take a few hundred more pages to ensure that you have seen an example of almost any type of query you may want to write, these past two chapters should leave you very prepared to venture forth.

In Chapter 6, you will learn about updating the data you have queried and taking advantage of stored procedures. Then, beginning with Chapter 9, you will start to write some small applications and be able to leverage many of these types of queries.

[3] (November 1, 2007).

Get Programming Entity Framework, 2nd Edition now with the O’Reilly learning platform.

O’Reilly members experience books, live events, courses curated by job role, and more from O’Reilly and nearly 200 top publishers.
