September 2003
Intermediate to advanced
608 pages
14h 50m
English
Overview
The complete guide to understanding and designing for signal integrity
Suitable for even non-specialists, Signal Integrity—Simplified offers a comprehensive, easy-to-follow look at how physical interconnects affect electrical performance. World-class engineer Eric Bogatin expertly reviews the root causes of the four families of signal integrity problems and offers solutions to design them out early in the design cycle. Coverage includes:
An introduction to signal integrity and physical design
A fundamental understanding of what bandwidth, inductance, and characteristic impedance really mean
Analysis of resistance, capacitance, inductance, and impedance
The four important practical tools used to solve signal integrity problems: rules of thumb, analytic approximations, numerical simulation, and measurements
The effect of the physical design of interconnects on signal integrity
Solutions that do not hide behind mathematical derivations
Recommendations for design guidelines to improve signal integrity, and much more
Unlike related books that concentrate on theoretical derivation and mathematical rigor, this book emphasizes intuitive understanding, practical tools, and engineering discipline. Specially designed for everyone in the electronics industry, from electrical engineers to product managers, Signal Integrity—Simplified will prove itself an invaluable resource for helping you find and fix signal integrity problems before they become problems.
