OpenOffice provides a suite of applications whose native file format consists of a set of XML files, compressed into a ZIP archive. This hack explores the basics of the OpenOffice file format.
OpenOffice (http://www.openoffice.org) is a suite of free, multiplatform, open source applications for the desktop, sponsored by Sun Microsystems (http://wwws.sun.com/software/star/openoffice/). The suite includes text-editor, spreadsheet, drawing, and presentation applications, each of which uses an XML-based file format. Table 4-2 lists the OpenOffice applications and their file extensions.
Each file is saved as a collection of XML documents and stored in a ZIP archive. (You can also save documents in other formats, such as text, Rich Text Format, or HTML. You can also export a document as PDF.) The specification of the OpenOffice XML file format is being maintained by an OASIS technical committee (http://www.oasis-open.org/committees/tc_home.php?wg_abbrev=office).
Table 4-2. OpenOffice applications and file extensions
In the OpenOffice subdirectory of the book’s file archive is a small file, foaf.sxw , a snippet taken from the FOAF hack [Hack #64] . It is shown in OpenOffice’s Writer application in Figure 4-5. You can use any ZIP tool to examine or extract the XML files from this ZIP file. I’ll use the unzip command-line tool that comes with Unix distributions such as Cygwin (http://www.cygwin.com).
While in the OpenOffice subdirectory, enter this command at a shell prompt:
unzip -l foaf.sxw
The -l option allows you to inspect the contents
of the compressed file without extracting the files from it. This
command produces:
Archive: foaf.sxw
Length Date Time Name
-------- ---- ---- ----
30 04-04-04 04:51 mimetype
4178 04-04-04 04:51 content.xml
8062 04-04-04 04:51 styles.xml
1174 04-04-04 04:51 meta.xml
9180 04-04-04 04:51 settings.xml
752 04-04-04 04:51 META-INF/manifest.xml
-------- -------
23376 6 filesExtract these files into the OpenOffice subdirectory with:
unzip foaf.sxw
You’ll see this:
Archive: foaf.sxw extracting: mimetype inflating: content.xml inflating: styles.xml extracting: meta.xml inflating: settings.xml inflating: META-INF/manifest.xml
Briefly, here’s what each of these files contains:
- mimetype
Contains the file’s media type; e.g.,
application/vnd.sun.xml.writer.- content.xml
Holds the text content of the file.
- meta.xml
Holds any meta information for the document. You can edit the meta information associated with this document by selecting File → Properties.
- settings.xml
Contains information about the settings of the document.
- styles.xml
Stores the styles applied to the document. You can apply styles to the document by selecting Format → Stylist (or by pressing F11).
- META-INF/manifest.xml
Contains a list of XML and other files that make up the default OpenOffice representation of the document.
Tip
When you do a File → Save As, you can click the “Save with password” checkbox. If you do this, all the XML files except meta.xml are saved as encrypted files.
For illustration, we’ll look at one of the files stored in the OpenOffice saved-file archive. Example 4-12 shows the XML markup that’s inside content.xml . This document is nicely indented because in the Tools → Options Load/Save dialog box under General settings, I’ve unchecked the Size optimization for XML format (no pretty printing) checkbox. It’s checked by default, meaning that normally the XML files are saved without indentation.
Example 4-12. content.xml from foaf.sxw
<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE office:document-content PUBLIC
"-//OpenOffice.org//DTD OfficeDocument 1.0//EN" "office.dtd">
<office:document-content
xmlns:office="http://openoffice.org/2000/office"
xmlns:style="http://openoffice.org/2000/style"
xmlns:text="http://openoffice.org/2000/text"
xmlns:table="http://openoffice.org/2000/table"
xmlns:draw="http://openoffice.org/2000/drawing"
xmlns:fo="http://www.w3.org/1999/XSL/Format"
xmlns:xlink="http://www.w3.org/1999/xlink"
xmlns:number="http://openoffice.org/2000/datastyle"
xmlns:svg="http://www.w3.org/2000/svg"
xmlns:chart="http://openoffice.org/2000/chart"
xmlns:dr3d="http://openoffice.org/2000/dr3d"
xmlns:math="http://www.w3.org/1998/Math/MathML"
xmlns:form="http://openoffice.org/2000/form"
xmlns:script="http://openoffice.org/2000/script"
office:class="text" office:version="1.0">
<office:script/>
<office:font-decls>
<style:font-decl style:name="Tahoma1" fo:font-family="Tahoma"/>
<style:font-decl style:name="Lucida Sans Unicode"
fo:font-family="'Lucida Sans Unicode'"
style:font-pitch="variable"/>
<style:font-decl style:name="MS Mincho"
fo:font-family="'MS Mincho'"
style:font-pitch="variable"/>
<style:font-decl style:name="Tahoma" fo:font-family="Tahoma"
style:font-pitch="variable"/>
<style:font-decl style:name="Times New Roman"
fo:font-family="'Times New Roman'"
style:font-family-generic="roman"
style:font-pitch="variable"/>
<style:font-decl style:name="Arial" fo:font-family="Arial"
style:font-family-generic="swiss" style:font-pitch="variable"/>
</office:font-decls>
<office:automatic-styles>
<style:style style:name="P1" style:family="paragraph"
style:parent-style-name="Text body">
<style:properties fo:text-align="center"
style:justify-single-word="false"/>
</style:style>
<style:style style:name="fr1" style:family="graphics"
style:parent-style-name="Graphics">
<style:properties style:vertical-pos="top"
style:vertical-rel="paragraph"
style:horizontal-pos="center" style:horizontal-rel="paragraph"
style:mirror="none" fo:clip="rect(0inch 0inch 0inch 0inch)"
draw:luminance="0%"
draw:contrast="0%" draw:red="0%" draw:green="0%" draw:blue="0%"
draw:gamma="1"
draw:color-inversion="false" draw:transparency="0%"
draw:color-mode="standard"/>
</style:style>
</office:automatic-styles>
<office:body>
<text:sequence-decls>
<text:sequence-decl text:display-outline-level="0"
text:name="Illustration"/>
<text:sequence-decl text:display-outline-level="0"
text:name="Table"/>
<text:sequence-decl text:display-outline-level="0"
text:name="Text"/>
<text:sequence-decl text:display-outline-level="0"
text:name="Drawing"/>
</text:sequence-decls>
<text:h text:style-name="Heading 1" text:level="1">Identify Yourself with FOAF,
an Application of RDF</text:h><text:p text:style-name="Text body">
FOAF provides a framework for creating and publishing personal information
in a machine-readable fashion. As you learn FOAF, you will also
get acquainted with RDF in a practical way as well.</text:p>
<text:p text:style-name="Text body">The Friend of a Friend or FOAF project
(http://www.foaf-project.org/) is a community-driven effort to define an RDF
vocabulary for expressing metadata about people, and their interests,
relationships and activities. Founded by Dan Brickley and Libby Miller, the FOAF
project is an open community-lead initiative which is tackling head-on the wider
Semantic Web goal of creating a machine processable web of data. Achieving this
goal quickly requires a network-effect that will rapidly yield a mass of data.
Network effects mean people. It seems a fairly safe bet that any early Semantic
Web successes are going to be riding on the back of people-centric applications.
Indeed, arguably everything interesting that we might want to describe on the
Semantic Web was created by or involves people in some form or another. And FOAF
is all about people.</text:p><text:p text:style-name="Text body">
FOAF facilitates the creation of the Semantic Web equivalent of the
archetypal personal homepage: My name is Leigh, this is a picture of me,
I'm interested in XML, and here are some links to my friends. And
just like the HTML version, FOAF documents can be linked together to form a web
of data, with well-defined semantics.</text:p><text:p text:style-name=
"Text body"> Being a W3C Resource Description Framework or RDF application
(http://www.w3.org/RDF/) means that FOAF can claim the usual benefits of being
easily harvested and aggregated. And like all RDF vocabularies, it can be
easily combined with other vocabularies, allowing the capture of a very rich set
of metadata. This hack introduces the basic terms of the FOAF vocabulary,
illustrating them with a number of examples. The hack concludes with a brief
review of the more interesting FOAF applications and considers some other uses
for the data. The FOAF graphic is shown in Figure A-1.</text:p>
<text:p text:style-name="P1">Figure A-1: FOAFlets</text:p>
<text:p text:style-name="Text body"/>
<text:p text:style-name="Text body">
<draw:image draw:style-name="fr1"
draw:name="Graphic1" text:anchor-type="paragraph" svg:width="4.2201inch"
svg:height="2.4299inch" draw:z-index="0"
xlink:href="#Pictures/10000000000001A6000000F34FFA992C.jpg"
xlink:type="simple"xlink:show="embed" xlink:actuate="onLoad"/></text:p>
</office:body>
</office:document-content>The XML documents in OpenOffice use DTDs
[Hack #68]
that come with the installed
package, though XML Schema and RELAX NG schemas will be available in
future versions. For example, on Windows, these files are installed
by default in C:\Program
Files\OpenOffice.org1.1.1\share\dtd\officedocument\1_0.
This document uses office.dtd (line 3). (These
DTDs are not in the book’s file archive.) On line 4,
the office:document-content element is the
document element with the namespace
http://openoffice.org/2000/office. Many other
namespaces are declared, along with some familiar ones, such as for
SVG
[Hack #9]
and XSL-FO
[Hack #48]
.
Various font declarations are stored in
style:font-decl elements on lines 21 through 37.
Attributes with the fo: prefix properties from
XSL-FO. Lines 38 through 56 list styles that are used in the
document. Lines 58 to 67 contain markup used for numeric sequencing
in the document. A heading appears on line 68, followed by body text
in lines 69 through 97. Lines 98 through 106 show how OpenOffice
defines a reference to a graphic, including attributes from the SVG
and XLink namespaces such as svg:width and
xlink:href. The embedded graphic is stored in the
Pictures subdirectory of
foaf.sxw as the file
For details on the OpenOffice file format, see the OASIS OpenOffice specification: http://www.oasis-open.org/committees/download.php/6037/office-spec-1.0-cd-1.pdf
For documentation and examples of working with OpenOffice XML, see J. David Eisenberg’s OpenOffice.org XML Essentials (http://books.evc-cit.info/)
