The nodes in this figure represent the people, and the lines represent the communica-

tion paths. The number of possible communications paths more than doubled when the

number of team members increased from four to six.

In general, the number of communication paths for

n people is SUM(n–1), where SUM is

the arithmetic sum function of

1, 2, . . . , n. Thus a modest increase from a 4-person team

to a 12-person team would increase the potential number of communication paths from

6 to 66. A tripling of a small team would increase the potential communication paths by

more than ten times!

Associated with this increase in the sheer number of communication paths is the

chance of an error in communications. Consider, for example, that the chance of com-

municating correctly a particular message between any two people is 2/3. The prob-

ability that we will communicate properly from one person to another and then from

that second person to a third person would be (2/3 3 2/3) = 4/9. In general, for n people

where n is 2 or more, the probability of correctly communicating this message would be

(2/3)

n21

. Thus for this message, there is only a 16/81 chance of correctly passing it from

the first person to the fifth person in the team. Suddenly, we have reduced a 2/3 chance

of correctly communicating a message to less than 1/4. Such a low probability of correct

communication among team members may be a serious problem, especially if the mes-

sage is critical. Organizational structures of people need to be put in place to reduce the

complexity and increase the chance of correct communications.

2.2 Building a Hypothetical System

In this section we will use a hypothetical payroll system to illustrate some of the prob-

lems introduced in Section 2.1. The discussion here will cover the major tasks of develop-

ing such a system and of supporting the system once it is released to users. The intent

of this section is to provide only a glimpse of the different problems and concerns that

arise in building our system but not to delve into all the details of constructing and sup-

porting this system.

2.2.1 Requirements of the Payroll System

Everyone has some idea of what a payroll system is. Take a moment to think about what

you would consider as the major functional and the nonfunctional requirements of a

Figure 2.4 Maximizing communication paths.

1 path 6 paths 15 paths

30 Chapter 2 Building a System
