Chapter 4. YARN
Apache YARN (Yet Another Resource Negotiator) is Hadoop’s cluster resource management system. YARN was introduced in Hadoop 2 to improve the MapReduce implementation, but it is general enough to support other distributed computing paradigms as well.
YARN provides APIs for requesting and working with cluster resources, but these APIs are not typically used directly by user code. Instead, users write to higher-level APIs provided by distributed computing frameworks, which themselves are built on YARN and hide the resource management details from the user. The situation is illustrated in Figure 4-1, which shows some distributed computing frameworks (MapReduce, Spark, and so on) running as YARN applications on the cluster compute layer (YARN) and the cluster storage layer (HDFS and HBase).
There is also a layer of applications that build on the frameworks shown in Figure 4-1. Pig, Hive, and Crunch are all examples of processing frameworks that run on MapReduce, Spark, or Tez (or on all three), and don’t interact with YARN directly.
This chapter walks through the features in YARN and provides a basis for understanding later chapters in Part IV that cover Hadoop’s distributed processing frameworks.
Anatomy of a YARN Application Run
YARN provides its core services via two types of long-running daemon: a resource manager (one per cluster) to manage the use of resources across the cluster, and node managers running on all the nodes in the cluster to launch and monitor containers. A container executes an application-specific process with a constrained set of resources (memory, CPU, and so on). Depending on how YARN is configured (see YARN), a container may be a Unix process or a Linux cgroup. Figure 4-2 illustrates how YARN runs an application.
To run an application on YARN, a client contacts the resource manager and asks it to run an application master process (step 1 in Figure 4-2). The resource manager then finds a node manager that can launch the application master in a container (steps 2a and 2b). Precisely what the application master does once it is running depends on the application. It could simply run a computation in the container it is running in and return the result to the client. Or it could request more containers from the resource managers (step 3), and use them to run a distributed computation (steps 4a and 4b). The latter is what the MapReduce YARN application does, which we’ll look at in more detail in Anatomy of a MapReduce Job Run.
Notice from Figure 4-2 that YARN itself does not provide any way for the parts of the application (client, master, process) to communicate with one another. Most nontrivial YARN applications use some form of remote communication (such as Hadoop’s RPC layer) to pass status updates and results back to the client, but these are specific to the application.
YARN has a flexible model for making resource requests. A request for a set of containers can express the amount of computer resources required for each container (memory and CPU), as well as locality constraints for the containers in that request.
Locality is critical in ensuring that distributed data processing algorithms use the cluster bandwidth efficiently, so YARN allows an application to specify locality constraints for the containers it is requesting. Locality constraints can be used to request a container on a specific node or rack, or anywhere on the cluster (off-rack).
Sometimes the locality constraint cannot be met, in which case either no allocation is made or, optionally, the constraint can be loosened. For example, if a specific node was requested but it is not possible to start a container on it (because other containers are running on it), then YARN will try to start a container on a node in the same rack, or, if that’s not possible, on any node in the cluster.
In the common case of launching a container to process an HDFS block (to run a map task in MapReduce, say), the application will request a container on one of the nodes hosting the block’s three replicas, or on a node in one of the racks hosting the replicas, or, failing that, on any node in the cluster.
A YARN application can make resource requests at any time while it is running. For example, an application can make all of its requests up front, or it can take a more dynamic approach whereby it requests more resources dynamically to meet the changing needs of the application.
Spark takes the first approach, starting a fixed number of executors on the cluster (see Spark on YARN). MapReduce, on the other hand, has two phases: the map task containers are requested up front, but the reduce task containers are not started until later. Also, if any tasks fail, additional containers will be requested so the failed tasks can be rerun.
The lifespan of a YARN application can vary dramatically: from a short-lived application of a few seconds to a long-running application that runs for days or even months. Rather than look at how long the application runs for, it’s useful to categorize applications in terms of how they map to the jobs that users run. The simplest case is one application per user job, which is the approach that MapReduce takes.
The second model is to run one application per workflow or user session of (possibly unrelated) jobs. This approach can be more efficient than the first, since containers can be reused between jobs, and there is also the potential to cache intermediate data between jobs. Spark is an example that uses this model.
The third model is a long-running application that is shared by different users. Such an application often acts in some kind of coordination role. For example, Apache Slider has a long-running application master for launching other applications on the cluster. This approach is also used by Impala (see SQL-on-Hadoop Alternatives) to provide a proxy application that the Impala daemons communicate with to request cluster resources. The “always on” application master means that users have very low-latency responses to their queries since the overhead of starting a new application master is avoided.
Building YARN Applications
Writing a YARN application from scratch is fairly involved, but in many cases is not necessary, as it is often possible to use an existing application that fits the bill. For example, if you are interested in running a directed acyclic graph (DAG) of jobs, then Spark or Tez is appropriate; or for stream processing, Spark, Samza, or Storm works.
There are a couple of projects that simplify the process of building a YARN application. Apache Slider, mentioned earlier, makes it possible to run existing distributed applications on YARN. Users can run their own instances of an application (such as HBase) on a cluster, independently of other users, which means that different users can run different versions of the same application. Slider provides controls to change the number of nodes an application is running on, and to suspend then resume a running application.
Twill is similar to Slider, but in addition provides a simple programming
model for developing distributed applications on YARN. Twill allows you
to define cluster processes as an extension of a Java
Runnable, then runs them in
YARN containers on the cluster. Twill also provides support for, among
other things, real-time logging (log events from runnables are streamed
back to the client) and command messages (sent from the client to
In cases where none of these options are sufficient—such as an application that has complex scheduling requirements—then the distributed shell application that is a part of the YARN project itself serves as an example of how to write a YARN application. It demonstrates how to use YARN’s client APIs to handle communication between the client or application master and the YARN daemons.
YARN Compared to MapReduce 1
The distributed implementation of MapReduce in the original version of Hadoop (version 1 and earlier) is sometimes referred to as “MapReduce 1” to distinguish it from MapReduce 2, the implementation that uses YARN (in Hadoop 2 and later).
It’s important to realize that the old and new MapReduce APIs are not the same thing as the MapReduce 1 and MapReduce 2 implementations. The APIs are user-facing client-side features and determine how you write MapReduce programs (see Appendix D), whereas the implementations are just different ways of running MapReduce programs. All four combinations are supported: both the old and new MapReduce APIs run on both MapReduce 1 and 2.
In MapReduce 1, there are two types of daemon that control the job execution process: a jobtracker and one or more tasktrackers. The jobtracker coordinates all the jobs run on the system by scheduling tasks to run on tasktrackers. Tasktrackers run tasks and send progress reports to the jobtracker, which keeps a record of the overall progress of each job. If a task fails, the jobtracker can reschedule it on a different tasktracker.
In MapReduce 1, the jobtracker takes care of both job scheduling (matching tasks with tasktrackers) and task progress monitoring (keeping track of tasks, restarting failed or slow tasks, and doing task bookkeeping, such as maintaining counter totals). By contrast, in YARN these responsibilities are handled by separate entities: the resource manager and an application master (one for each MapReduce job). The jobtracker is also responsible for storing job history for completed jobs, although it is possible to run a job history server as a separate daemon to take the load off the jobtracker. In YARN, the equivalent role is the timeline server, which stores application history.
The YARN equivalent of a tasktracker is a node manager. The mapping is summarized in Table 4-1.
YARN was designed to address many of the limitations in MapReduce 1. The benefits to using YARN include the following:
YARN can run on larger clusters than MapReduce 1. MapReduce 1 hits scalability bottlenecks in the region of 4,000 nodes and 40,000 tasks, stemming from the fact that the jobtracker has to manage both jobs and tasks. YARN overcomes these limitations by virtue of its split resource manager/application master architecture: it is designed to scale up to 10,000 nodes and 100,000 tasks.
In contrast to the jobtracker, each instance of an application—here, a MapReduce job—has a dedicated application master, which runs for the duration of the application. This model is actually closer to the original Google MapReduce paper, which describes how a master process is started to coordinate map and reduce tasks running on a set of workers.
High availability (HA) is usually achieved by replicating the state needed for another daemon to take over the work needed to provide the service, in the event of the service daemon failing. However, the large amount of rapidly changing complex state in the jobtracker’s memory (each task status is updated every few seconds, for example) makes it very difficult to retrofit HA into the jobtracker service.
With the jobtracker’s responsibilities split between the resource manager and application master in YARN, making the service highly available became a divide-and-conquer problem: provide HA for the resource manager, then for YARN applications (on a per-application basis). And indeed, Hadoop 2 supports HA both for the resource manager and for the application master for MapReduce jobs. Failure recovery in YARN is discussed in more detail in Failures.
In MapReduce 1, each tasktracker is configured with a static allocation of fixed-size “slots,” which are divided into map slots and reduce slots at configuration time. A map slot can only be used to run a map task, and a reduce slot can only be used for a reduce task.
In YARN, a node manager manages a pool of resources, rather than a fixed number of designated slots. MapReduce running on YARN will not hit the situation where a reduce task has to wait because only map slots are available on the cluster, which can happen in MapReduce 1. If the resources to run the task are available, then the application will be eligible for them.
Furthermore, resources in YARN are fine grained, so an application can make a request for what it needs, rather than for an indivisible slot, which may be too big (which is wasteful of resources) or too small (which may cause a failure) for the particular task.
In some ways, the biggest benefit of YARN is that it opens up Hadoop to other types of distributed application beyond MapReduce. MapReduce is just one YARN application among many.
It is even possible for users to run different versions of MapReduce on the same YARN cluster, which makes the process of upgrading MapReduce more manageable. (Note, however, that some parts of MapReduce, such as the job history server and the shuffle handler, as well as YARN itself, still need to be upgraded across the cluster.)
Since Hadoop 2 is widely used and is the latest stable version, in the rest of this book the term “MapReduce” refers to MapReduce 2 unless otherwise stated. Chapter 7 looks in detail at how MapReduce running on YARN works.
Scheduling in YARN
In an ideal world, the requests that a YARN application makes would be granted immediately. In the real world, however, resources are limited, and on a busy cluster, an application will often need to wait to have some of its requests fulfilled. It is the job of the YARN scheduler to allocate resources to applications according to some defined policy. Scheduling in general is a difficult problem and there is no one “best” policy, which is why YARN provides a choice of schedulers and configurable policies. We look at these next.
Three schedulers are available in YARN: the FIFO, Capacity, and Fair Schedulers. The FIFO Scheduler places applications in a queue and runs them in the order of submission (first in, first out). Requests for the first application in the queue are allocated first; once its requests have been satisfied, the next application in the queue is served, and so on.
The FIFO Scheduler has the merit of being simple to understand and not needing any configuration, but it’s not suitable for shared clusters. Large applications will use all the resources in a cluster, so each application has to wait its turn. On a shared cluster it is better to use the Capacity Scheduler or the Fair Scheduler. Both of these allow long-running jobs to complete in a timely manner, while still allowing users who are running concurrent smaller ad hoc queries to get results back in a reasonable time.
The difference between schedulers is illustrated in Figure 4-3, which shows that under the FIFO Scheduler (i) the small job is blocked until the large job completes.
With the Capacity Scheduler (ii in Figure 4-3), a separate dedicated queue allows the small job to start as soon as it is submitted, although this is at the cost of overall cluster utilization since the queue capacity is reserved for jobs in that queue. This means that the large job finishes later than when using the FIFO Scheduler.
With the Fair Scheduler (iii in Figure 4-3), there is no need to reserve a set amount of capacity, since it will dynamically balance resources between all running jobs. Just after the first (large) job starts, it is the only job running, so it gets all the resources in the cluster. When the second (small) job starts, it is allocated half of the cluster resources so that each job is using its fair share of resources.
Note that there is a lag between the time the second job starts and when it receives its fair share, since it has to wait for resources to free up as containers used by the first job complete. After the small job completes and no longer requires resources, the large job goes back to using the full cluster capacity again. The overall effect is both high cluster utilization and timely small job completion.
Figure 4-3 contrasts the basic operation of the three schedulers. In the next two sections, we examine some of the more advanced configuration options for the Capacity and Fair Schedulers.
Capacity Scheduler Configuration
The Capacity Scheduler allows sharing of a Hadoop cluster along organizational lines, whereby each organization is allocated a certain capacity of the overall cluster. Each organization is set up with a dedicated queue that is configured to use a given fraction of the cluster capacity. Queues may be further divided in hierarchical fashion, allowing each organization to share its cluster allowance between different groups of users within the organization. Within a queue, applications are scheduled using FIFO scheduling.
As we saw in Figure 4-3, a single job does not use more resources than its queue’s capacity. However, if there is more than one job in the queue and there are idle resources available, then the Capacity Scheduler may allocate the spare resources to jobs in the queue, even if that causes the queue’s capacity to be exceeded. This behavior is known as queue elasticity.
In normal operation, the Capacity Scheduler does not preempt containers by forcibly killing them, so if a queue is under capacity due to lack of demand, and then demand increases, the queue will only return to capacity as resources are released from other queues as containers complete. It is possible to mitigate this by configuring queues with a maximum capacity so that they don’t eat into other queues’ capacities too much. This is at the cost of queue elasticity, of course, so a reasonable trade-off should be found by trial and error.
Imagine a queue hierarchy that looks like this:
root ├── prod └── dev ├── eng └── science
The listing in Example 4-1 shows a
sample Capacity Scheduler configuration file, called capacity-scheduler.xml, for this hierarchy.
It defines two queues under the
dev, which have 40% and 60% of the capacity,
respectively. Notice that a particular queue is configured by setting
configuration properties of the form
is the hierarchical (dotted) path of the queue, such as
As you can see, the
is further divided into
science queues of equal capacity. So
dev queue does not use up
all the cluster resources when the
prod queue is idle, it has its maximum
capacity set to 75%. In other words, the
prod queue always has 25% of the cluster
available for immediate use. Since no maximum capacities have been set
for other queues, it’s possible for jobs in the
science queues to use all of the
dev queue’s capacity (up to 75% of the
cluster), or indeed for the
queue to use the entire cluster.
Beyond configuring queue hierarchies and capacities, there are settings to control the maximum number of resources a single user or application can be allocated, how many applications can be running at any one time, and ACLs on queues. See the reference page for details.
The way that you specify which queue an application is placed in
is specific to the application. For example, in MapReduce, you set the
the name of the queue you want to use. If the queue does not
exist, then you’ll get an error at submission time. If no queue is
specified, applications will be placed in a queue called
For the Capacity Scheduler, the queue name should be the last
part of the hierarchical name since the full hierarchical name is
not recognized. So, for the preceding example configuration,
eng are OK, but
dev.eng do not work.
Fair Scheduler Configuration
The Fair Scheduler attempts to allocate resources so that all running applications get the same share of resources. Figure 4-3 showed how fair sharing works for applications in the same queue; however, fair sharing actually works between queues, too, as we’ll see next.
The terms queue and pool are used interchangeably in the context of the Fair Scheduler.
To understand how resources are shared between queues, imagine two users A and B, each with their own queue (Figure 4-4). A starts a job, and it is allocated all the resources available since there is no demand from B. Then B starts a job while A’s job is still running, and after a while each job is using half of the resources, in the way we saw earlier. Now if B starts a second job while the other jobs are still running, it will share its resources with B’s other job, so each of B’s jobs will have one-fourth of the resources, while A’s will continue to have half. The result is that resources are shared fairly between users.
Enabling the Fair Scheduler
The scheduler in use is determined by the setting of
.class. The Capacity Scheduler is used by
default (although the Fair Scheduler is the default in some Hadoop
distributions, such as CDH), but this can be changed by setting
.scheduler.class in yarn-site.xml to the fully qualified
classname of the scheduler,
The Fair Scheduler is configured using an allocation file named
fair-scheduler.xml that is loaded
from the classpath. (The name can be changed by setting the property
yarn.scheduler.fair.allocation.file.) In the
absence of an allocation file, the Fair Scheduler operates as
described earlier: each application is placed in a queue named after
the user and queues are created dynamically when users submit their
Per-queue configuration is specified in the allocation file.
This allows configuration of hierarchical queues like those supported
by the Capacity Scheduler. For example, we can define
dev queues like we did for the Capacity
Scheduler using the allocation file in Example 4-2.
The queue hierarchy is defined using nested
queue elements. All queues are children of
root queue, even if not
actually nested in a
queue element. Here we subdivide the
dev queue into a queue called
eng and another called
Queues can have weights, which are used in the fair share
calculation. In this example, the cluster allocation is considered
fair when it is divided into a 40:60 proportion between
science queues do not have weights
specified, so they are divided evenly. Weights are not quite the same
as percentages, even though the example uses numbers that add up to
100 for the sake of simplicity. We could have specified weights of 2
and 3 for the
dev queues to achieve the same queue
When setting weights, remember to consider the default queue and dynamically created queues (such as queues named after users). These are not specified in the allocation file, but still have weight 1.
Queues can have different scheduling policies. The default
policy for queues can be set in the top-level
defaultQueueSchedulingPolicy element; if it
is omitted, fair scheduling is used. Despite its name, the Fair
Scheduler also supports a FIFO (
fifo) policy on queues, as well as Dominant
Resource Fairness (
later in the chapter.
The policy for a particular queue can be overridden using the
schedulingPolicy element for that
queue. In this case, the
uses FIFO scheduling since we want each production job to run serially
and complete in the shortest possible amount of time. Note that fair
sharing is still used to divide resources between the
dev queues, as well as between (and within)
Although not shown in this allocation file, queues can be configured with minimum and maximum resources, and a maximum number of running applications. (See the reference page for details.) The minimum resources setting is not a hard limit, but rather is used by the scheduler to prioritize resource allocations. If two queues are below their fair share, then the one that is furthest below its minimum is allocated resources first. The minimum resource setting is also used for preemption, discussed momentarily.
The Fair Scheduler uses a rules-based system to determine which
queue an application is placed in. In Example 4-2, the
queuePlacementPolicy element contains a list
of rules, each of which is tried in turn until a match occurs. The
specified, places an
application in the queue it specified; if none is specified, or if the
specified queue doesn’t exist, then the rule doesn’t match and the
next rule is tried. The
primaryGroup rule tries to place an
application in a queue with the name of the user’s primary Unix group;
if there is no such queue, rather than creating it, the next rule is
default rule is a
catch-all and always places the application in the
be omitted entirely, in which case the default behavior is as if it
had been specified with the following:
In other words, unless the queue is explicitly specified, the user’s name is used for the queue, creating it if necessary.
Another simple queue placement policy is one where all applications are placed in the same (default) queue. This allows resources to be shared fairly between applications, rather than users. The definition is equivalent to this:
It’s also possible to set this policy without using an
allocation file, by setting
false so that applications will be
placed in the default queue rather than a per-user queue. In
should be set to
false so that
users can’t create queues on the fly.
When a job is submitted to an empty queue on a busy cluster, the job cannot start until resources free up from jobs that are already running on the cluster. To make the time taken for a job to start more predictable, the Fair Scheduler supports preemption.
Preemption allows the scheduler to kill containers for queues that are running with more than their fair share of resources so that the resources can be allocated to a queue that is under its fair share. Note that preemption reduces overall cluster efficiency, since the terminated containers need to be reexecuted.
Preemption is enabled globally by setting
true. There are two relevant preemption
timeout settings: one for minimum share and one for fair share, both
specified in seconds. By default, the timeouts are not set, so you
need to set at least one to allow containers to be preempted.
If a queue waits for as long as its minimum share
preemption timeout without receiving its minimum
guaranteed share, then the scheduler may preempt other containers. The
default timeout is set for all queues via the
element in the allocation file, and on a per-queue basis by setting
element for a queue.
Likewise, if a queue remains below half of its fair share for as long as the
fair share preemption timeout, then the
scheduler may preempt other containers. The default timeout is set for
all queues via the
element in the allocation file, and on a per-queue basis by setting
fairSharePreemptionTimeout on a
queue. The threshold may also be changed from its default of 0.5 by
All the YARN schedulers try to honor locality requests. On a busy cluster, if an application requests a particular node, there is a good chance that other containers are running on it at the time of the request. The obvious course of action is to immediately loosen the locality requirement and allocate a container on the same rack. However, it has been observed in practice that waiting a short time (no more than a few seconds) can dramatically increase the chances of being allocated a container on the requested node, and therefore increase the efficiency of the cluster. This feature is called delay scheduling, and it is supported by both the Capacity Scheduler and the Fair Scheduler.
Every node manager in a YARN cluster periodically sends a heartbeat request to the resource manager—by default, one per second. Heartbeats carry information about the node manager’s running containers and the resources available for new containers, so each heartbeat is a potential scheduling opportunity for an application to run a container.
When using delay scheduling, the scheduler doesn’t simply use the first scheduling opportunity it receives, but waits for up to a given maximum number of scheduling opportunities to occur before loosening the locality constraint and taking the next scheduling opportunity.
For the Capacity Scheduler, delay scheduling is configured by
a positive integer representing the number of scheduling opportunities
that it is prepared to miss before loosening the node constraint to
match any node in the same rack.
The Fair Scheduler also uses the number of scheduling
opportunities to determine the delay, although it is expressed as a
proportion of the cluster size. For example, setting
0.5 means that the scheduler should wait until half of the nodes in the
cluster have presented scheduling opportunities before accepting another
node in the same rack. There is a corresponding property,
for setting the threshold before another rack is accepted
instead of the one requested.
Dominant Resource Fairness
When there is only a single resource type being scheduled, such as memory, then the concept of capacity or fairness is easy to determine. If two users are running applications, you can measure the amount of memory that each is using to compare the two applications. However, when there are multiple resource types in play, things get more complicated. If one user’s application requires lots of CPU but little memory and the other’s requires little CPU and lots of memory, how are these two applications compared?
The way that the schedulers in YARN address this problem is to look at each user’s dominant resource and use it as a measure of the cluster usage. This approach is called Dominant Resource Fairness, or DRF for short. The idea is best illustrated with a simple example.
Imagine a cluster with a total of 100 CPUs and 10 TB of memory. Application A requests containers of (2 CPUs, 300 GB), and application B requests containers of (6 CPUs, 100 GB). A’s request is (2%, 3%) of the cluster, so memory is dominant since its proportion (3%) is larger than CPU’s (2%). B’s request is (6%, 1%), so CPU is dominant. Since B’s container requests are twice as big in the dominant resource (6% versus 3%), it will be allocated half as many containers under fair sharing.
By default DRF is not used, so during resource calculations, only
memory is considered and CPU is ignored. The Capacity Scheduler can be
configured to use DRF by setting
This chapter has given a short overview of YARN. For more detail, see Apache Hadoop YARN by Arun C. Murthy et al. (Addison-Wesley, 2014).
 It’s also possible for the client to start the application master, possibly outside the cluster, or in the same JVM as the client. This is called an unmanaged application master.
 All of these projects are Apache Software Foundation projects.
 If the property
is set to a value larger than 1 (the default), then a single job is
allowed to use more than its queue’s capacity.
 However, the Capacity Scheduler can perform work-preserving preemption, where the resource manager asks applications to return containers to balance capacity.
 DRF was introduced in Ghodsi et al.’s “Dominant Resource Fairness: Fair Allocation of Multiple Resource Types,” March 2011.
