系统建模 | 39
外部实体是标准形状。至少，外部实体为从远程进程或机制进入系统的数据流
提供了一个来源。外部实体的例子通常包括用于访问 Web 服务器或类似服务的
Web 浏览器，但也可能包括任何类型的组件或处理单元。
图 1-3：用于绘制数据流图的外部实体符号
行为者（Actor）（参见图 1-4）主要代表系统的人类用户，是与系统提供的接口
有连接的标准形状 [ 直接连接，或通过一个中间的外部实体（如 Web 浏览器）
连接 ]，通常用于绘图的上下文层。
图 1-4：用于绘制数据流图的行为者符号
如图 1-5 所示，数据存储（Data store）符号是一种代表一个功能单元的标准形
状，该功能单元指示“大容量”数据保存在何处，例如数据库（但不总是数据
库服务器）。你还可以使用数据存储符号来指示包含少量与安全性相关的数据的
文件或缓冲区，例如，包含 Web 服务器 TLS 证书的私钥的文件
注 7
，或用于对象
数据存储 [ 例如 Amazon Simple Storage Service（S3）存储桶 ] 存放应用程序的
日志文件输出。数据存储符号也可以表示消息总线或共享内存区域。
1
图 1-5：用于绘制数据流图的数据存储符号
数据存储应该被标记并有如下的元数据。
存储类型
这是一个文件、S3 存储桶、服务网格还是一个共享内存区域 ?
注 7： 在 Apache Tomcat 中使用这种机制。
40 | 第
1
章
所持有数据的类型和分类
发送到该模块的数据或从该模块读取的数据是结构化的还是非结构化的？
是否采用任何特定格式，例如， ...
