IBM Tivoli Storage Manager in a Clustered Environment

452 IBM Tivoli Storage Manager in a Clustered Environment

9.1 Overview

Here is a brief overview of IBM Tivoli Storage Manager 5.3 enhancements.

9.1.1 Tivoli Storage Manager Version 5.3 new features overview

IBM Tivoli Storage Manager V5.3 is designed to provide some significant

improvements to ease of use as well as ease of administration and serviceability.

These enhancements help you improve the productivity of personnel who are

administering and using IBM Tivoli Storage Manager. Additionally, the product is

easier to use for new administrators and users.

򐂰 Improved application availability:

– IBM Tivoli Storage Manager for Space Management: HSM for AIX

JFS2,enhancements to HSM for AIX and Linux GPFS

– IBM Tivoli Storage Manager for application products update

򐂰 Optimized storage resource utilization:

– Improved device management, SAN attached device dynamic mapping,

native STK ACSLS drive sharing and LAN-free operations, improved tape

checkin, checkout, and label operations, and new device support

– Disk storage pool enhancements, collocation groups, proxy node support,

improved defaults, reduced LAN-free CPU utilization, parallel reclamation,

and migration

򐂰 Enhanced storage personnel productivity:

– New Administrator Web GUI

– Task-oriented interface with wizards to simplify tasks such as scheduling,

managing server maintenance operations (storage pool backup,

migration, reclamation), and configuring devices

– Health monitor which shows status of scheduled events, the database and

recovery log, storage devices, and activity log messages

– Calendar-based scheduling for increased flexibility of client and

administrative schedules

– Operational customization for increased ability to control and schedule

server operations

Chapter 9. AIX and HACMP with IBM Tivoli Storage Manager Server 453

Server enhancements, additions, and changes

This section lists all the functional enhancements, additions, and changes for the

IBM Tivoli Storage Manager Server introduced in Version 5.3.

Here are the latest changes:

򐂰 ACSLS Library Support Enhancements

򐂰 Accurate SAN Device mapping for UNIX Servers

򐂰 ACSLS Library Support Enhancements

򐂰 Activity Log Management

򐂰 Check-In and Check-Out Enhancements

򐂰 Collocation by Group

򐂰 Communications Options

򐂰 Database Reorganization

򐂰 Disk-only Backup

򐂰 Enhancements for Server Migration and Reclamation Processes

򐂰 IBM 3592 WORM Support

򐂰 Improved Defaults

򐂰 Increased Block Size for Writing to Tape

򐂰 LAN-free Environment Configuration

򐂰 NDMP Operations

򐂰 Net Appliance SnapLock Support

򐂰 New Interface to Manage Servers: Administration Center

򐂰 Server Processing Control in Scripts

򐂰 Simultaneous Write Inheritance Improvements

򐂰 Space Triggers for Mirrored Volumes

򐂰 Storage Agent and Library Sharing Fallover

򐂰 Support for Multiple IBM Tivoli Storage Manager Client Nodes

򐂰 IBM Tivoli Storage Manager Scheduling Flexibility

Client enhancements, additions and changes

This section lists all the functional enhancements, additions, and changes for the

IBM Tivoli Storage Manager Backup Archive Client introduced in Version 5.3.

Here are the latest changes:

򐂰 Include-exclude enhancements

򐂰 Enhancements to query schedule command

򐂰 IBM Tivoli Storage Manager Administration Center

򐂰 Support for deleting individual backups from a server file space

򐂰 Optimized option default values

򐂰 New links from the backup-archive client Java GUI to the IBM Tivoli Storage

Manager and Tivoli Home Pages

򐂰 New options, Errorlogmax and Schedlogmax, and DSM_LOG environment

variable changes

򐂰 Enhanced encryption

454 IBM Tivoli Storage Manager in a Clustered Environment

򐂰 Dynamic client tracing

򐂰 Web client enhancements

򐂰 Client node proxy support [asnodename]

򐂰 Java GUI and Web client enhancements

򐂰 IBM Tivoli Storage Manager backup-archive client for HP-UX Itanium 2

򐂰 Linux for zSeries offline image backup

򐂰 Journal based backup enhancements

򐂰 Single drive support for Open File Support (OFS) or online image backups.

9.1.2 Planning for storage and database protection

In this section we will give some considerations how to plan the storage and

Tivoli Storage Manager database protection. For more details, please refer to:

“Protecting and Recovering Your Server” in the Administrators Guide.

For this configuration example we chose to have:

Tivoli Storage Manager server:

򐂰 Code installed under rootvg filesystems /usr on both nodes

򐂰 Tivoli Storage Manager mirroring for database and log volumes

򐂰 RAID0 shared disks volumes configured on separate storage subsystem

arrays for database and log volumes copies

–/tsm/db1

– /tsm/db1mr

–/tsm/lg1

–/tsm/lg1mr

򐂰 Database and log writes set to sequential (which disables

DBPAGESHADOW)

򐂰 Log mode set to RollForward

򐂰 RAID1 shared disk volumes for configuration files and disk storage pools.

– /tsm/files

–/tsm/dp1

Tivoli Storage Manager Administration Center

Note: The Administration Center can be a critical application for environments

where administrator and operators are not confident with the

IBM Tivoli

Storage Manager Command Line Administrative Interface

. So we decided to

experiment with a clustered installation, even if it is not currently supported.
