header pins JD-VCC and VCC needs to be in place
as shown in the lower right. The 4-pin header in
the upper right connects to the PCB for power
and signals. A relay is activated when an input
receives a low (ground) signal, and an LED on the
module lights up.
When connecting the “hot” (black) side of
the 120V AC to the duplex plug from the relays,
remember to snap off the small connector
between the screws on that side so that each plug
will be controlled separately.
6. CONNECT THE JUMPERS
Connect the three 4-pin jumpers between the
4-pin headers on the PCB and the LCD, the
DS3231 RTC board, and the dual relay board.
7. MOUNT THE RTC BOARD
Mount ...
