Chapter 11. SNA over Ethernet 167
Figure 11-19 Define Descriptor Fields dialog
We then received a confirmation that the new production IODF had been created. We
pressed F3 the number of times needed to return to the ISPF main menu.
We next used the ISPF editor to modify line 2 of member LOAD01 of SYS1.IPLPARM on
ZP4SYS, as shown in Figure 11-20. We changed the ‘07’ to ‘08’ so that at the next IPL the
system would use SYS1.IODF08, the IODF we just created.
Figure 11-20 IPLPARM modification
We then IPLed the system to ensure that the osasna device was available to VTAM.
11.9 Defining the SSCPs, the subareas, and the network
Before the SSCPs can go ...
