174 EFS Systems on a Linux Base: Additional Topics
Figure 11-31 Member XCAE40E in ZPLEX.ZSNA.VTAMLST on zsna
11.12 Bringing up a link
On system z370, we varied the XCA node active and received the response shown in
Figure 11-32.
Figure 11-32 Vary Activate of the XCA node on z370
Not too much can be made of this response. We then went over to the zos1 system, and
activated its OSA link. We received the response shown in Figure 11-33.
Figure 11-33 Vary Activate of the OSA node on zos1
XCAE40 VBUILD TYPE=XCA
XPE40E PORT CUADDR=E40,ADAPNO=1,SAPADDR=8,MEDIUM=CSMACD, X
DELAY=0,TIMER=30
XGE40E GROUP DIAL=NO
XLZOS1 LINE USER=SNA,ISTATUS=ACTIVE
XPZOS ...
