8 Gear Drives

Photos of 12 gear drives.

Nomenclature

a
centre distance, mm
b
face width, mm
c
clearance, mm
d
diameter of reference or pitch circle, mm
d a
diameter of addendum circle, mm
d b
diameter of base circle, mm
d f
diameter of dedendum circle, mm
d m
mean diameter, mm
d 1t
trial diameter of pitch circle, mm
d v
pitch diameter of virtual spur gear, mm
E
elastic modulus, MPa
F a
axial force, or thrust force, N
F ca
design load, or actual load, N
F n
normal force, N
F r
radial force, or separating force, N
F t
tangential force, or transmitted force, N
h
tooth height, mm
h a
addendum, mm
h F
bending moment arm, mm
h f
dedendum, mm
i
Speed or velocity ratio, transmission ratio
j
number of gear teeth meshing per revolution
K
load factor
K A
application factor
K FN
life factor for bending stress
K HN
life factor for contact stress
K t
trial load factor
K v
dynamic factor
K α
transverse load factor
K β
face load factor
L
contact length, mm
L h
design life in hours, h
l
lead, mm
m
module, mm
m m
mean module , mm
m n
normal module, mm
m nt
trial normal module, mm
m t
transverse module, mm
N
number of load cycles
n
rotational speed, rpm
P
transmitted power, kW
p a
axial pitch, ...
