14 Springs

3D illustrations of various types of helical springs, Belleville springs, spiral springs, leaf springs and ring springs.

Nomenclature

b
slenderness ratio
C
spring index
D
mean diameter, mm
D i
inside diameter, mm
D o
outside diameter, mm
d
spring wire diameter, mm
E
modulus of elasticity, MPa
F
external axial force, N
f n
fundamental natural frequency, Hz
G
shear modulus, MPa
g
gravity acceleration, m s−2
H f
free height/length of spring, mm
H h
length of hook, mm
H i
installed height/length, mm
H o
operating height/length, mm
H s
solid height/length, mm
h
working distance of a spring, mm
I
moment of inertia of spring wire, mm4
J
polar moment of inertia, mm4
K w
Wahl factor
K wT
Wahl factor for torsion spring
k
spring rate, N mm−1, N m−1
k ϕ
spring rate of torsion spring, N mm/(°)
L
length of wire, mm
M
bending moment, N mm
m
mass of spring, kg
n
number of active coils
n total
total number of coils
p
spring pitch, mm
S
shear force, N
S ca
fatigue strength safety factor
T
torsional moment, N mm
U
strain energy, J
U 0
energy loss due to friction, J
W
section modulus, mm3
w
work for a deflection under a load, J
α
pitch angle, °
δ
coil clearance, mm
δ 1
coil clearance at the maximum load, mm
λ
deflection, mm
ρ
density, kg m−3
σ
bending stress, MPa
σ b
ultimate tensile ...
