10 Shafts

Photos of various shafts.

Nomenclature

d
shaft diameter, mm
d v
equivalent diameter of a stepped shaft, mm
E
elastic modulus, MPa
F
force, N
G
shear modulus of elasticity, MPa
g
acceleration of gravity, mm/s2
I
moment of inertia, mm4
J
polar moment of inertia, mm4
K
cantilever length, mm
k
shaft stiffness or shaft spring rate, N/m
L
calculated length of a shaft, mm
l
span, mm
M
resultant bending moment, N mm
M ca
equivalent bending moment, N mm
M H
horizontal bending moment, N mm
M V
vertical bending moment, N mm
m
mass, kg
m n
normal module, mm
n
rotational speed, rpm
n c
critical speed, rpm
P
transmitted power, kW
S
safety factor
S ca
calculated safety factor
S σ
safety factor in tension
[S]
allowable safety factor
T
torque, N mm
W
section modulus, mm3
W T
polar section modulus, mm3
w i
weight of ith mass, N
y
deflection, mm
[y]
allowable deflection, mm
z
number of segments in a stepped shaft
α
correction coefficient
θ
slope, rad
[θ]
allowable slope, rad
σ
normal stress, MPa
σ −1
endurance limit at stress ratio of −1, MPa
σ a
stress amplitude, MPa
σ b
ultimate tensile strength, MPa
σ ca
design stress, MPa
σ m
mean stress, MPa
σ s
yield strength in tension, MPa
[σ −1]
allowable bending ...
