In Figure 0.1, resistor R3 is electrically connected to resistor R2 in one side and to RE on the other.
3.2 Unspecified Value
If a component does not have its value specified in a schematic in this book, the following rules must be followed: every resistor is always expressed in Ohms, every capacitor in Farads, every inductor in Henries, and every power ...
