Lab Exercises 53
a. Show it in the form of a collaboration diagram.
b. Show it in the form of a sequence diagram.
Q1-13 Draw a state diagram for a behavior that sends the command bits on
the track. The machine should generate the address, generate the cor rect
message type, include the parameters, and generate the ECC.
Q1-14 Draw a state diagram for a behavior that parses the received bits. The
machine should check the address, determine the message type, read the
parameters, and check the ECC.
Q1-15 Draw a class diagram for the classes required in a basic microwave oven.
The system should be able to set the microwave power level between
1 and 9 and
