CHAPTER 6
The Smith Chart
OBJECTIVES
1. Understand the structure of the Smith chart.
2. Know the features and capabilities of the Smith chart.
3. Be able to interpret a Smith chart plot.
4. Learn to draw Smith chart plots.
6-1 PREQUIZ
These questions test your prior knowledge of the material in this chapter. Try an-
swering them before you read the chapter. Look for the answers (especially those
you answered incorrectly) as you read the text. After you have finished studying the
chapter, try answering these questions again and those at the end of the chapter.
1. A Smith chart consists of a series of circles that depict complex ...
