The desired detector for each pixel is selectable with the ROIC data words.

Fourteen FPMs are organized in two rows of seven each such that the detec-

tors have overlap so as to produce a contiguous detector array (after process-

ing) to cover the desired swath of 185 km. For optimal SWIR performance,

the FPA is passively cooled to 210 K. The AT spectral band separation leads

to an approximately 0.96-s time delay between the rst and the last band.

Since the detectors are displaced AT, the yaw axis is steered to compensate

for cross-track image motion due to the Earth’s rotation. The satellite also has

an ...
