FIGURE 2.7 Higher modes vs. VFI (P) at a/h = 5 for PM2.

TABLE 2.7

Frequency Parameter with Varying P and

˜

at a/b=1 for PM2

PM2 VFI

˜

a/h 1 4 10 50 100

5 0 0.1543 0.1294 0.1206 0.1092 0.1065

0.1 0.1524 0.1236 0.1143 0.1021 0.0990

0.2 0.1496 0.1153 0.1054 0.0924 0.0888

0.3 0.1453 0.1017 0.0910 0.0782 0.0739

0.4 0.1385 0.0731 0.0589 0.0500 0.0463

10 0 0.0420 0.0357 0.0335 0.0300 0.0292

0.1 0.0414 0.0342 0.0318 0.0281 0.0271

0.2 0.0406 0.0319 0.0295 0.0255 0.0244

0.3 0.0394 0.0281 0.0257 0.0217 0.0204

0.4 0.0374 0.0199 0.0167 ...
