19.4. Domain Model vs. Design Model Classes
To reiterate, in the UP Domain Model, a Sale does not represent a software definition; rather, it is an abstraction of a real-world concept about which we are interested in making a statement. By contrast, DCDs express—for the software application—the definition of classes as software components. In these diagrams, a Sale represents a software class (see Figure 19.2).
Figure 19.2. Domain model vs. Design Model classes.
