Silverston c06.tex V2 - 11/21/2008 3:09am Page 259
Level 2 Status Pattern, Current Status 259
Table 6-2 Example of Using the Level 2 Status Pattern, Current Status
ORDER. ORDER. ORDER. STATUS TYPE. STATUS
ORDER ORDER STATUS STATUS TYPE.
ID DESCRIPTION DATETIME TYPE ID NAME
12560 Deluxe Mobile
Phone
Feb. 2, 2010, 2 p.m. 10 Order Opened
12560 Deluxe Mobile
Phone
Feb. 2, 2010, 3 p.m. 55 Order Received
12560 Deluxe Mobile
Phone
Feb. 2, 2010, 4 p.m. 20 Order Entered
12560 Deluxe Mobile
Phone
Feb. 3, 2010, 9 a.m. 30 Order Confirmed
12560 Deluxe Mobile
Phone
Feb. 19, 2010, 6
p.m.
60 Order Closed
23000 Mobile Phone
Standard
Feb. 2, 2010, 2 p.m. 10 Order Opened
23000 Mobile Phone
Standard
Feb. 2, 2010, 2 p.m. 55 Order Received
23000 Mobile Phone
Standard
Feb. 2, 2010, 6 p.m. 20 Order Entered
23000 Mobile Phone
Standard
Feb. 3, 2010, 9 a.m. 30 Order Confirmed
23000 Mobile Phone
Standard
Feb. 4, 2010, 2 p.m. 70 Order Cancelled
23000 Mobile Phone
Standard
Feb. 14, 2010 60 Order Closed
32999 Mobile Phone
Accessories
Mar. 3, 2010, 3 p.m. 10 Order Opened
InthecaseoftheinstanceofORDERwithorder id of ‘‘23000’’ the order life
cycle encompasses six different states: ‘‘Order Opened,’’ ‘‘Order Received,’’
‘‘Order Entered,’’ ‘‘Order Confirmed,’’ ‘‘Order Cancelled,’’ and the final status
‘‘Order Closed.’’ This again complies with Figure 6-1. The last row in the
table shows an instance of ORDER with order id ‘‘32999’’ for ‘‘Mobile Phone
Accessories’’
