Chapter 12
Plotting Your Drawings
The final step of the drawing process is to communicate the design to others through both paper and electronic media.
Objectives
After completing this chapter, you will be able to:
- Create and activate page setups.
- Plot design geometry from model space or from a layout.
Standard Object Snap and Status Bar Settings
Before completing the exercises in this chapter, refer to the “Settings for the Exercises” section in the Introduction.
