Nodal Analysis and
Mesh Analysis
Nodal Analysis uses
the KVL and element
equations to eliminate
voltage variables,
reduces the number of
pertinent variables to
(n 1) node voltage
variables and uses the
KCL equations to solve
for these node voltage
variables.
Mesh Analysis uses
KCL and element
equations to eliminate
current variables,
reduces the number of
pertinent variables to
(b n 1) mesh current
variables and uses the
KVL equations to solve
for these variables.
122
4 NODAL ANALYSIS AND MESH ANALYSIS OF MEMORYLESS CIRCUITS
v
1
(t), v
2
(t), v
3
(t) and v
4
(t) are the time-functions which describe the voltage delivered
by the independent voltage sources.
Thus, we have ...
