148 Internet of Things
The given diagram above can help us to use UML to explain the dynamic nature of a system,
the structural allocation, and interaction between the objects. The given diagram has a start and
end point, similar to any other activity diagram. Then, on the top-level view, you will be able
to see the interactions and interactions utilities by the use of rectangular boxes. This diagram
works as complete stand-alone sequence diagram that consists of the three main actors: the
inspector, the assistant, and the middleware reporting system. Once the sequence of actions is
executed, the flow state arms out and either reciprocates ...
