Make: Robotic Arms

63Chapter 3: Inverse Kinematics for 2D Movement

#include <Servo.h>

Servo servoOne;

Servo servoTwo;

double x = 120.0;

double y = 120.0;

double linkOne = 100.0;

double linkTwo = 100.0;

double thetaOne;

double thetaTwo;

void setup() {

Serial.begin(9600);

servoOne.attach(3);

servoTwo.attach(5);

}

void loop()

{

thetaOne = (atan(y/x) +

acos(((linkTwo*linkTwo)

-((x*x)+(y*y))-(linkOne*linkOne))/

(-2*(linkOne)*(sqrt((x*x)+(y*y))))));

double thetaOneDeg = (thetaOne*(180/PI));

thetaTwo = (acos((((x*x)+(y*y))-(linkTwo*linkTwo)

-(linkOne*linkOne)) /

(-2*(linkOne)*(linkTwo))));

double thetaTwoDeg = (thetaTwo*(180/PI));

servoOne.write(thetaOneDeg);

servoTwo.write(thetaTwoDeg); ...
