380 CHAPTER 8 / ARITHMETIC DEVICES AND ARITHMETIC LOGIC UNITS (ALUs)
FIGURE 8.48
The three least significant bit stages of an n-bit arithmetic module for a PALU with CLA and comple-
tion signal capability showing the carry generate/propagate (CGP) network required for the dual-rail
carries and carry generate parameters.
logic 0 (G
0
, P
), as required for dual-rail carries. This is demonstrated in Fig. 8.48, where
for simplicity only the arithmetic module is featured. Notice that the carry-in’s for the
LSB stage are properly initialized for addition or 2’s complement arithmetic. Hence, for
subtraction,
Add/Sub = 1 introduces a logic 1 into C
in
1 and a logic ...
